7MBR50VR120-56 1200V 50A PIM Module Integrated Rectifier Inverter and Brake Low Loss High Isolation Built-in NTC Compact Package For Industrial Motor Drives and UPS

Features

• Power Integrated Module (PIM)

• 1200V / 50A Rating

• Integrated 3-in-1 Function: 3-Phase Rectifier, 3-Phase Inverter, Brake Chopper

• Low Vce(sat) IGBTs and Low Vf Diodes (High Efficiency)

• High Electrical Isolation

• Built-in NTC Temperature Sensor

• Compact and Isolated Package

• Simplifies PCB Layout and Thermal Design

• High Reliability for Industrial Environments

Applications

• Compact Industrial AC Motor Drives / Variable Frequency Drives (VFD): For pumps, fans, and conveyor systems.

• Servo Drive Systems.

• Uninterruptible Power Supply (UPS) Inverter and Rectifier Stages.

• General-Purpose Industrial Inverters.

• Appliances and HVAC Systems requiring robust power control.

Description

The 7MBR50VR120-56 is a highly integrated Power Integrated Module (PIM) designed to offer a compact and complete power solution for industrial motor drives and UPS inverters. It integrates the essential power components for a typical variable frequency drive into a single, isolated package: a three-phase input rectifier bridge, a three-phase IGBT inverter bridge with freewheeling diodes, and a brake chopper circuit. Rated for 1200V and 50A, this module significantly reduces system size, component count, and design complexity. It features low-loss IGBTs and diodes for high efficiency, provides high electrical isolation for safety, and includes a built-in NTC thermistor for accurate temperature monitoring and protection. This all-in-one design enhances reliability and simplifies thermal management.
