The 0.75kW to 18.5kW Electrical Control Panel is a specialized distribution and motor-starting solution designed for indoor industrial and commercial applications. Engineered to house motor starters, contactors, and protection relays, this cabinet serves as the primary control point for small-to-medium machinery, water pumps, and ventilation systems.

Constructed from high-grade cold-rolled steel, this 63A rated switchgear box provides a compact and safe environment for managing power. Whether you are implementing a Direct-On-Line (DOL) starter for a 0.75kW motor or a more complex Star-Delta configuration for an 18.5kW load, this panel offers the mechanical protection and wiring flexibility required for professional electrical installations.

• Optimized for Motor Loads: Specifically designed to accommodate thermal overload relays and circuit breakers for motors ranging from 1HP (0.75kW) to 25HP (18.5kW).

• Precision Steel Fabrication: Fabricated from 1.2mm to 1.5mm thick cold-rolled metal, finished with an electrostatic epoxy powder coating (RAL 7035) for superior scratch and oil resistance.

• Compact 63A Architecture: Designed for high-efficiency sub-distribution. The internal layout maximizes space for DIN-rail components while ensuring enough clearance for heat dissipation and cable bending.

• Enhanced Safety Features: Features a secure single-point lock and internal grounding studs on both the door and the main body to ensure continuous electrical bonding and operator safety.

• Customizable Interface: The front panel can be factory-drilled for 22mm pilot lights, push buttons, and E-stop switches, providing an intuitive control interface for the operator.

1. Industrial Pump Control: Localized control for sump pumps, irrigation pumps, and pressure booster sets.

2. HVAC Systems: Starting and protecting centrifugal fans, air handling units, and small compressors.

3. Manufacturing Machinery: Power distribution for conveyors, CNC auxiliary systems, and small milling machines.

4. Commercial Building Services: Reliable control panels for elevator machine rooms and lighting sub-circuits.

• Turnkey Customization: We offer "Fully Populated" panels pre-wired with Chint, Schneider, or ABB components, or "Empty Shells" for local panel builders.

• Removable Gland Plate: The bottom entry features a removable plate for easy drilling, ensuring a clean and professional cable entry process during on-site installation.

• High Conductivity: Every pre-wired unit utilizes high-purity copper wiring and tinned terminal blocks to prevent oxidation and ensure stable voltage delivery.

• Direct Factory Support: Gain the advantage of manufacturer-direct pricing and technical support, with CAD drawings provided for approval before bulk production begins.

Q: Can this box support a Star-Delta starter for an 18.5kW motor?

A: Yes. The 18.5kW model is sized to accommodate the three contactors and timer necessary for Star-Delta starting, ensuring adequate spacing for wiring.

Q: Is it possible to get a transparent window on the door?

A: We offer optional polycarbonate viewing windows so that maintenance staff can check the status of breakers or pilot lights without opening the cabinet.

Q: Does the 0.75kW version use the same size box as the 18.5kW version?

A: No. We provide scaled enclosure sizes. The 0.75kW boxes are compact for space-saving, while the 11kW-18.5kW boxes are larger to facilitate thermal management.

JXF series distribution box is suited for operating in the circuit of AC 50Hz, rated operating voltage 500V and below, in some special cases, the protection grade can reach up to IP55, the top and bottom of the panel will provide knockout holes, if multiple pipes are used for incoming lines, opening plate can be prepared, maxi rated current up to 400A, especially suitable for usage in metering and control box of mining field, hotel, living buildings and etc. Comply with GB7251.12-2013 Low voltage switchgear and
controlgear, IEC60439-2:2011 Low voltage switchgear and controlgear standard.
