Cable Joints 600A Integral Deadbreak Bushing
Cable Joints 600A Integral Deadbreak Bushing
Specifications
Place of Origin :
Zhejiang
Brand Name :
CNLB
color :
black
Model Number :
TCJCTG/600A
CURRENT :
600A
Category :
Other Wiring Accessories
Description

1.specialize in Deadbreak cable accessory
2.High quality
3.lowest price
4.CE and ISO9001:2000
5.600A

-

--

rated current:600A
rated voltage:15kV

1. 15KV/600A
2. deadbreak Bushing
3. Integral Deadbreak
4. cable joints
5. with KEMA report

-

The RU YTGZ-15/600 Integral Deadreak Bushing( cable joints)-combines the advantages of reliable integral design with the operating features required for three-phase switching. The bushing is designed for pad mounted transformers, switchgear and other apparatus fliled with transformer oil, or an approved equivalent. It eliminates the insert-to-well interface present in bushing well and insert primary terminations.

-

The Bushing is molded with high quality insulating material. When mated with comparably rated products, it provides a fully shielded, submersible and separable connection for deadbreak operation.

-

The-RU YTGZ-15/600 Integral Bushing includes two kinds. Type A is used in oil-insulated apparatus and type B is suitable for the air-insulated devices.

-

Interchangeability

-

All-RU Power System 600A Integral Deadbreak Bushing conform to the electrical,

mechanical and dimensional requirements of ANSI/IEEE Standard 386. The Integral

Deadbreak Bushing can be used on any comparably rated connector interface that

also meets the requirements of this standard.

-

Electrical Characteristics:

Voltage Rating and Characteristics

Description

kv

Standard Voltage Class

15

Max Rating Phase to phase

14.4

Max Phase to ground

8.3

AC 50 Hz 1 minute Withstand

42

DC 15 minute Withstand

53

BIL and Full Wave Crest

95

15kv Partial Discharge

≤10PC

Current Ratings and Characteristics

Description

Amperes

Continuous

600A

24 hours overhead

1000A

Short time

50kA rms symmetrical for 0.3s

20kA rms symmetrical for 4.0s

Electrical Characteristics are in accordance with or exceed GB/T 12706.4-2002, ANSI/IEE 386-1995, IEC 60502-4:1997
