separable connector, 200A,15kV Grounding Elbow
separable connector, 200A,15kV Grounding Elbow
Specifications
Place of Origin :
Zhejiang
Brand Name :
CNLB
color :
black
Model Number :
TCJDTT-15/200
CURRENT :
200A
VOLTAGE :
15KV
TYPE :
T type
Category :
Wires, Cables & Cable Assemblies
Description

1.specialize in Deadbreak connector
2.High quality
3.lowest price
4.CE and ISO9001:2000
5.200A 15KV

General

The CEE JDT-15/200 Grounding Elbows have become part of the preferred operating procedure for deadfront underground systems because they take advantage of the fault close-in characteristics of loadbreak terminators. It is the essential component for testing the cables and underground apparatus.
A Grounding elbow can be used either itself or with a 200A,15kV Class rated Loadbreak Bushing Insert, Rotatable Feedthru to visibly ground cables, transformers and switchgear. A grounding elbow at each end of a cable will isolate and ground the cable and keep bushings free from moisture and contamination during the grounding operation.


The grounding elbow is molded of high quality orange insulating rubber and features a copper connector and tin plated copper probe complete with an arc follower tip. A 2-metre length of 600 volt insulated, flexible stranded copper ground cable is included. Determine whether the circuit is de-energized. Attach the ground cable to the system ground. Use a hot-stick to attach the grounding elbow to the mating apparatus.

-

Interchangeability

All CEE Power System 200A Grounding Elbow connectors conform to the electrical, mechanical and dimensional requirements of ANSI/IEEE Standard 386. The loadbreak elbow connectors can be used on any comparably rated bushing interface that also meets the requirements of this standard.

--

-

-

-

-

-
