PCB Inspection Machine with 5 HD Digital Flat Panel Detector and 530x530mm Table
PCB Inspection Machine with 5 HD Digital Flat Panel Detector and 530x530mm Table
Specifications
Brand Name :
WELLMAN
Model Number :
X-Ray X-6800
Certification :
CE,FDA,ISO9001
Place of Origin :
China
Payment Terms :
T/T
Packaging Details :
Wooden case
Description
PCB Inspection Machine with 5" HD Digital Flat Panel Detector and 530x530mm Table
Key Advantages
  • Closed type X-ray tube with over 10,000 hours lifetime, maintenance-free operation
  • New generation 5" HD digital flat panel detector (FPD)
  • FPD tilts up to 60° without sacrificing magnification
  • Automatic navigation window - table moves to clicked position
  • 530×530mm table with 10KG load capacity
  • Speed adjustable 5-axis linkage system
  • Programmable inspection procedures for automated batch inspection
  • Easy operation with quick defect detection - only 2 hours training required
Working Principle
PCB Inspection Machine with 5
Hardware Specifications
X-ray Source
TypeClosed, microfocus
Max Tube Voltage90kV (110kV, 130kV optional)
Max Tube Current200μA
Focal Spot Size5μm (4μm, 2μm optional)
FunctionAuto preheat
Flat Panel Detector
Tiltable Angle60°
Effective Area130mm×130mm
Pixel Size85μm
Resolution1536×1536
Frame Rate20fps
Table
Max Load10kg
Size530mm×530mm
Detectable Area500mm×500mm
Equipment
MagnificationGeometry 200X | System 1500X
Inspection SpeedMax 3.0s/point
Dimensions1360mm (L) × 1365mm (W) × 1730mm (H)
Weight1200kg
Max Power1500W
Power SupplyAC110-220V 50/60HZ
Industrial PCI5 CPU, 8G RAM, 500GB SSD
Displayer24" HDMI LCD
Safety Features
  • Radiation Leakage: No leakage, international standard: ≤1μSv/h
  • Lead Glass Observation Window: Transparent lead glass window shields radiation to observe inner status
  • Window and Back Door Safety Interlock: X-ray tube powers off immediately when window or door is opened
  • Electromagnetic Safety Switch: Locks when X-ray is on
  • Emergency Stop: Located next to operation position for immediate power cutoff
  • Tube Protection: Software prevents leaving without closing X-ray tube
Software Capabilities
Function ModuleDescription
OperationComplete control via keyboard and mouse
X-ray Tube ControlMouse-click activation with real-time voltage/current display and adjustment
Status BarVisual indication of interlock, pre-heat, and X-ray status
Image Effect AdjustmentBrightness, contrast and gain adjustment for optimal imaging
Product ListSave and recall inspection parameters for efficiency
Navigation WindowClick-to-move table positioning with camera guidance
Motion Axis StatusReal-time coordinate display
Inspection ResultOrganized display of measurement results (voids rate, distance, area)
Speed ControlAdjustable movement speed for each axis
Voids Rate MeasurementAutomatic calculation of solder ball voids with NG/OK indication
Parameters AdjustmentCustomizable grayscale threshold, pixel, contrast, and size filtering
Add Voids ManuallyManual void designation via polygon or free-form drawing
Save ParametersStore measurement settings for product-specific inspection
Distance MeasurementPoint-to-baseline distance calculation
Distance RatePercentage ratio measurement for through-hole soldering rate
Angle MeasurementAngle calculation between defined rays
Radius MeasurementCircle measurement for round components like solder balls
Perimeter MeasurementSquare component measurement for length, width and area
Automatic InspectionProgrammable inspection points with automatic image capture
Array InspectionGrid-based automatic inspection for regular patterns
Automatic IdentificationFeature-based position recognition and measurement
Application Examples
PCB Inspection Machine with 5
BGA Solder Bridge
PCB Inspection Machine with 5
BGA Solder Voids
PCB Inspection Machine with 5
PCB Through-Hole
PCB Inspection Machine with 5
IC Voids and Gold Wire
PCB Inspection Machine with 5
LED Solder Voids
PCB Inspection Machine with 5
LED Gold Wire Crack
PCB Inspection Machine with 5
Capacitor
PCB Inspection Machine with 5
Inductor
PCB Inspection Machine with 5
Sensor
PCB Inspection Machine with 5
Thyristor Surge Suppressors
PCB Inspection Machine with 5
Fiberglass
PCB Inspection Machine with 5
Cable
PCB Inspection Machine with 5
Diode
PCB Inspection Machine with 5
Steel Pipe Welding Gap
PCB Inspection Machine with 5
Automotive Electronics
