Specifications
Brand Name :
Bitvisus
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$1,243-1,715
Input Interface :
1xHDMI2.0/1xDPI 1.2a
Output Interface :
15xHDMI1.3
Input Resolution :
7680x4320@60Hz
Output Resolution :
1920x1080@60Hz
Power Supply :
DC 12V 5A
Maximum Power :
22W
Input Pixel Clock :
600MHz
Output Pixel Clock :
165MHz
Input Cable Length :
5m (4K60), 10m (1080P60)
Output Cable Length :
15m (1080P60)
Control Method :
PC host/serial port protocol RS232/RS485/TTL
Window Layout :
Any window opening, overlay, roaming
Material :
Metal
Storage Temperature :
-10～50ºC
Working Temperature :
0～50ºC
Description
8K60 Magic Control Box with 15-Screen Display Capability
Professional 8K video wall processor featuring instant creative display with 64GB built-in storage, advanced playback capabilities, and flexible splicing effects for any shape configuration.
Key Features
  • Ultra-high resolution support for 8K60 (7680x4320P60Hz)
  • HDMI/DP input interfaces with HDMI output interfaces
  • 1 HDMI 2.0 capture input with 15 HDMI 1.3 outputs
  • Flexible any splicing mode within 9 screens combination
  • Fixed EDID design supporting customized input resolution
  • Supports 1xN, Nx1, NxN, point to point display modes
  • No stretching, no deformation, no compression output
  • FPGA chip technology for real-time data processing with zero delay
  • 15-screen splicing at any angle and any shape configuration
Application Scenarios
Multi-screen liquid crystal display showroom exhibitions, video projector showroom exhibitions, monitoring or command centers, multimedia video teaching, engineering conference rooms, and digital medical displays.
Product Images
8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor 8K60 Video Wall Controller with 15-Screen Splicing and FPGA Chip for Multi-Screen Processor
Technical Specifications
Input Specifications
Input Interface 2 HDMI 2.0/DP 1.2 (either one)
HDCP Function Supports HDCP 2.2
Transmission Distance ≤5 meters
Input Maximum Pixel Clock 600MHz
Input Single Port Resolution 3840x2160@60Hz/3840x2400@60Hz
5760x3240@30Hz/7680x2160@30Hz
(Resolution 4Kx2K@60Hz)
Input Color Format RGB888, 24bit
Output Specifications
Output Interface 9 HDMI 1.3
Transmission Distance ≤15 meters
Output Maximum Pixel Clock 165M
Output Single Port Resolution 1920x1080@60Hz
1920x1200@60Hz
(customizable)
Audio & Power Specifications
Audio Output HDMI follow-through, 3.5mm audio jack (audio split)
Power Supply DC 12V/2A
Maximum Power Consumption 22W
Storage/Working Temperature -10～50ºC/0～50ºC
List of Accessories 12V/2A Power Supply*1, HDMI/DP Cable*2, Certificate of Conformity*1, Warranty Card*1
Frequently Asked Questions
Why Choose Bitvisus?
  • Own warehouse ensuring shipping within 48 hours after payment (excluding weekends and holidays)
  • OEM/ODM services available for custom requirements
  • Leading manufacturer in video wall processing technology
How to Order?
  • Contact via email, TM, WhatsApp, or Skype with your order requirements
  • Receive proforma invoice based on your order request
  • Review PI and complete payment for prompt delivery
Warranty & After-Sale Service
  • 12 months warranty with lifetime service support
  • Return or exchange available for faulty, damaged, or wrong model items
Shipment & Payment
  • Payment methods: T/T, Visa, PayPal, Western Union, L/C
  • Shipping carriers: DHL, UPS, EMS, FedEx, Air freight, Sea freight
