Specifications
Brand Name :
Bitvisus
Model Number :
BIT-Dec64-09
Certification :
CE、FCC、GB
Place of Origin :
Guangdong China
MOQ :
1
Price :
858
Payment Terms :
T/T
Supply Ability :
1000
Delivery Time :
5-8 work days
Packaging Details :
3.7KG, 54cm*29cm*11cm
Product name :
BIT-Dec64-09
Product type :
4K60 Decoding and splicing processor
Resolution :
Decoding of 64xD1@30fps/16x1080p@30fps H.265/1.264
Feature :
Display the video of 64-channel IPC
Function :
Decoding and splicing processor
Input :
1 x Gigabit Ethernet ports
Output :
9xHDMI 1.4,1 xHDMI 1.4(Loop)
Decoding performance :
Decoding of 64xD1@30fps/16x1080p@30fps H.265/1.264
Output Interface :
154MHz
Warranty :
3 Years
Description
4K 64 Opening Windows 9 HDMI Output Decoder IP Stream Input Security Monitoring Decoder 9 Screen Splitting Video Wall Processor
Product Overview
  • Supports 9-channel HDMI outputs and 1-channel HDMI loop-through output
  • Single device offers 9-channel HDMI outputs with flexible splicing modes (landscape, portrait, quadrilateral arrangements)
  • Energy-efficient design with internal conduction cooling for high reliability
  • High-performance SoC chip for secure, integrated HD intelligent NVR solution
  • Supports decoding of 64xD1@30fps H.265/H.264 or 16x1080p@30fps H.265/H.264
  • Gigabit Ethernet ports for high-speed connectivity
  • Web-based control for easy operation (window roaming, splitting, merging)
  • Batch import/export of IPC for rapid device deployment
  • Pre-set plan saving and polling for quick display scheme switching
  • Subtitle settings and customizable video background color
  • Electronic map positioning with IPC video echo
Welcome to contact us to consult about the products required by your project!
Product Specifications
Product Name BIT-Dec64-09
Input Port 1 x Gigabit Ethernet ports
Decoding performance 64xD1@30fps H.265/H.264 decode or 16x1080p@30fps H.265/H.264 decode
Output port 9xHDMI 1.4, 1 xHDMI 1.4 (Loop)
Output resolution 1920x1080p60, 1920x1200p60
Maximum pixel clock frequency of output 154MHz
Color depth 8bit
Control method Web
Power supply voltage 12V
Power consumption 26W
Operating temperature -10~70°C/0~70°C
Product size 483mm (Length) x 162mm (Width) x 60mm (Height)
Package size 530mm (Length) x 280mm (Width) x 95mm (Height)
Product weight 3KG
Packing weight 4.6KG
Accessories list 1 x 12V 5A power adapter, 1 x CAT5E Ethernet cable
After-sales warranty 3-year warranty
Features at a Glance
4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding
Company Profile
4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding 4K60 Video Wall Processor 9 HDMI Output 64-Channel Decoding
FAQ
Why Choose Bitvisus?
  • Own warehouse ensures shipping within 48 hours after payment (weekends/holidays excluded)
  • OEM/ODM services available
  • Extensive product range including Video Wall controllers, Multiscreen Expanders, Multiviewers, and Embedded Projector Fusion systems
Shipment & Payment
  • Payment methods: T/T, Visa, PayPal, Western Union, L/C
  • Shipping options: DHL, UPS, EMS, FedEx, Air freight, Sea freight
How to Order?
  1. Contact us via email or chat (TM, WhatsApp, Skype) with your requirements
  2. We'll provide a proforma invoice based on your order
  3. After payment confirmation, we'll ship your order promptly
