High Efficiency Drilling Rig 10-35m/h Footage For Indonesia/Vietnam
High Efficiency Drilling Rig 10-35m/h Footage For Indonesia/Vietnam
High Efficiency Drilling Rig 10-35m/h Footage For Indonesia/Vietnam
High Efficiency Drilling Rig 10-35m/h Footage For Indonesia/Vietnam
Specifications
Brand Name :
SHITAN
Model Number :
ST200s
Certification :
ISO,CE
Place of Origin :
China
MOQ :
1SET
Price :
Negotiate
Payment Terms :
T/T,Western Union
Supply Ability :
500set
Delivery Time :
7-15 workday
Packaging Details :
Wooden Box
Type :
Water Well Rotary Drilling Rig
Max drilling depth :
0-260m
Key Selling Points :
High working efficiency
Warranty :
1 year
Drilling diameter :
105-300mm
Rotary speed :
30/120r/min
Video outgoing-inspection :
Provided
Transportation method :
Sea freight
Description
High Efficiency Drilling Rig 10-35m/h Footage For Indonesia/Vietnam
This high-efficiency drilling rig is engineered for Southeast Asia construction projects, covering industrial and civilian applications including geothermal drilling. With a working air pressure of 1.25-3.5Mpa, it delivers fast footage rates and flexible mobility. The rig features a 73KW engine optimized for Southeast Asian power environments, easy procurement of drill pipe accessories, and a 35m leg stroke that adapts to complex terrain, making it a cost-effective solution for regional drilling engineering.
Technical Specifications
Footage Efficiency 10-35m/h
Climbing Degree 30°
Maximum Rotation Speed 85/170r/min
Drill Pipe Diameter 76mm
Maximum Turning Torque 5900 N·m
Overall Dimension 3.4*1.8*2.3m
Adaptive Conditions Loose layer and bedrock
Working Wind Pressure 1.25-3.5Mpa
Key Operational Benefits
  • Maximum drilling depth of 260 meters, meeting deep hole geothermal and civilian drilling requirements in Southeast Asia
  • Drilling diameter range of 105-305mm, suitable for large aperture construction scenarios
  • Equipped with 73KW Xidong engine providing strong power output optimized for Southeast Asian working conditions
  • Standard drill rod length of 3m with 76mm diameter, ensuring easy accessory procurement in Southeast Asian markets
  • Total machine weight of 6T for convenient transportation and cross-border logistics throughout Southeast Asia
  • Supports three drilling methods: top drive hydraulic rotation, down the hole impact, and mud drilling for strong geological adaptability
