18T Lifting Force Heavy Duty Rock Drilling Rig Suitable For Bedrock Drilling
18T Lifting Force Heavy Duty Rock Drilling Rig Suitable For Bedrock Drilling
18T Lifting Force Heavy Duty Rock Drilling Rig Suitable For Bedrock Drilling
18T Lifting Force Heavy Duty Rock Drilling Rig Suitable For Bedrock Drilling
Specifications
Brand Name :
SHITAN
Model Number :
ST200s
Certification :
ISO,CE
Place of Origin :
China
MOQ :
1SET
Price :
Negotiate
Payment Terms :
T/T,Western Union
Supply Ability :
500set
Delivery Time :
5-8 workday
Packaging Details :
Wooden Box
Type :
Rotary Drilling Rig
Use :
Water Well
Core Components :
motor, Pump, Engine
Key Selling Points :
High working efficiency
Video outgoing-inspection :
Provided
Fast fonwarding speed :
5900
Rotary speed :
30/120r/min
Trade methods :
DDP CIF DAP etc.
Transportation method :
Sea freight
Sales regions :
Southeast Asia, Africa and other countries and regions
Description
18T Lifting Force Heavy Duty Rock Drilling Rig - Suitable For Bedrock Drilling
The ST200s water well drilling rig is a high-performance solution for industrial, civil, and geothermal drilling applications. With a maximum drilling depth of 200 meters and diameter range of 105-300mm, it excels in both loose layers and bedrock formations. Powered by a 65KW Xidong 4-cylinder engine, it delivers efficient drilling speeds of 10-35m/h with strong 18T lifting force and 20m/min fast lifting speed.
Technical Specifications
Country of Origin Hebei, China
Drilling Method Air compressor or mud pump
Walking Style Four-wheel drive vehicle
Drilling Diameter 105-300mm
Drilling Depth 0-200m / 656 feet
Air Consumption 16-55m³/min
Moving Speed 21 km/h
Overall Size 4.5m × 1.8m × 2.1m
Advanced Features
Equipped with hydraulic rotary top drive and compatible with medium/high air pressure hammers, the ST200s supports both DTH (Down-The-Hole) and mud drilling methods. Its 4WD design, 21° climbing capacity, and 5.5T lightweight body ensure excellent mobility and easy transshipment. Optional accessories including mud pumps and generators enhance operational versatility for global drilling projects.
Key Benefits
  • Professional technical team provides customized drilling solutions
  • Comprehensive after-sales system ensures timely repair and maintenance
  • Ample spare parts supply prevents project delays
  • Advanced production equipment ensures high precision and consistency
  • Experienced assembly team conducts rigorous whole-machine debugging
  • Free operation training for quick and easy equipment operation
  • Direct manufacturer supply offers better value and worry-free service
Product Gallery

Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：

Pneumatic Drilling Rig / Air Drilling Rig（ST-180,ST-200,ST-260,ST-300,ST-350,ST-400,ST450,ST-450,ST-500, ST-600,ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B,GK180, GK200, GY150, GY200 and 30 impact drill rig,ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter

Good quality, professional after-sales service, welcome to order
