M20 IP68 Quick Connector Straight Male Female 2 Pin Push Wire Screw Connector
M20 IP68 Quick Connector Straight Male Female 2 Pin Push Wire Screw Connector
M20 IP68 Quick Connector Straight Male Female 2 Pin Push Wire Screw Connector
M20 IP68 Quick Connector Straight Male Female 2 Pin Push Wire Screw Connector
M20 IP68 Quick Connector Straight Male Female 2 Pin Push Wire Screw Connector
M20 IP68 Quick Connector Straight Male Female 2 Pin Push Wire Screw Connector
Specifications
Supply Ability :
Can produce 10 million sets of wire harnesses annually
Model Number :
m20 assembly plug
IP Protection Rating :
IP67
MOQ :
5 sets
Delivery Time :
7-15 days
Housing Material :
Nickel-Plated Brass, Stainless Steel, Glass-Fiber Reinforced PA66 (Nylon)
Payment Terms :
L/C,D/A,D/P,T/T
Price :
3 USD -5 USD
Contact Resistance :
≤5mΩ - 10mΩ
Certification :
UL,CE certification
Contact Material :
Phosphor Bronze, Gold Plated
Brand Name :
kenhon
Withstand Voltage :
≥1500V AC (1 minute duration)
Place of Origin :
Shenzhen, Guangdong, China
Rated voltage :
300V-600V
Packaging Details :
10*10*10
Description
Product Overview
The M20 Inline Sealed Connector is a cylindrical power and signal interconnect featuring a straight tubular body with M20×1.5 threaded locking rings on each end. This connector joins two cable segments in a straight line while maintaining IP67/IP68 protection at the junction point. It serves as a reusable, field-terminable extension splice for outdoor and industrial cable applications.
Key Benefits
  • Cut-to-length cable joining with full environmental sealing
  • IP67 standard / IP68 optional protection against rainfall, pressure washing, dust, and submersion
  • 20A capacity within a compact 20mm barrel design
  • Field-terminable screw clamps for 0.5-2.5 mm² (24-14 AWG) cables
  • Keyed polarization prevents wiring errors
  • Industrial-grade copper alloy contacts with gold or silver plating
  • Reopenable and reusable design for maintenance and prototyping
  • Vibration-resistant threaded locking mechanism
Technical Specifications
Parameter Value
Coupling Thread M20 × 1.5 (PG13.5 compatible)
Body Style Straight inline / axial (I-type)
Pin Count 2 / 3 / 4 / 5
Rated Voltage 300 V AC/DC (2/3-pin), 250 V (4-pin), 110 V (5-pin)
Rated Current 20 A (2/3-pin), 12 A (4-pin), 5 A (5-pin)
Contact Resistance ≤ 5 mΩ
Insulation Resistance ≥ 100 MΩ @ 500 V DC
Dielectric Strength 1500 V AC / 1 min
Protection Level IP67 standard / IP68 optional (when mated)
Cable Diameter Range 5-12 mm (dependent on gland insert)
Wire Gauge 0.5-2.5 mm² (24-14 AWG) screw type
Operating Temperature -40 °C to +85/+105 °C
Shell Material PA66+GF, UL94-V0
Mating Cycle Life ≥ 3000 cycles
Certifications CE, RoHS, UL/CCC options per stock-keeping unit
Competitive Advantages
  • 60% smaller than junction boxes with no internal water traps
  • Maintains IP rating for years versus heat-shrink tubing
  • 5× the current capacity of M12 inline couplers
  • Cut any length on site versus pre-molded extension cords
Applications
  • Outdoor LED and street lighting systems
  • Solar photovoltaic and storage systems
  • Industrial automation and robotics
  • Surveillance and smart city infrastructure
  • Marine, RV, and agricultural equipment
  • Stage and event production systems
