Compact Swivel Wheel Sorter High Speed Sorting Conveyor With Quick Installation
Compact Swivel Wheel Sorter High Speed Sorting Conveyor With Quick Installation
Compact Swivel Wheel Sorter High Speed Sorting Conveyor With Quick Installation
Compact Swivel Wheel Sorter High Speed Sorting Conveyor With Quick Installation
Compact Swivel Wheel Sorter High Speed Sorting Conveyor With Quick Installation
Compact Swivel Wheel Sorter High Speed Sorting Conveyor With Quick Installation
Specifications
Brand Name :
Realkey
Model Number :
RKSORT-SWS
Certification :
CE/EAC/UL/ISO
Place of Origin :
China
MOQ :
1 unit
Price :
USD 10000/Piece
Payment Terms :
L/C,T/T,D/P
Custom Order :
Accept
OEM/ODM :
Accept
Fatory :
Direct Factory With Own Exporting Platform
Feature :
Breaking the limitation of manual sorting of large and irregular items
Description
Compact Swivel Wheel Sorter High Speed Sorting Conveyor With Quick Installation
Product Specifications
Attribute Value
Custom Order Accept
OEM/ODM Accept
Factory Direct Factory With Own Exporting Platform
Feature Breaking the limitation of manual sorting of large and irregular items
Product Overview
Ideal for E-commerce Warehouses Swivel Wheel Sorter Efficient Order Fulfillment Capabilities

The Swivel Wheel Sorting Machine, also known as the Divert Wheel Sorter or Rotating Wheel Sorter, is a highly effective solution designed for sorting parcels and cartons within conveyor systems. This machine consists of an electric drum (wheel), a steering system, a control unit, and a robust frame.
Technical Parameters
Model SWS-10M SWS-12H
Sorted Items Medium to large parcels, woven bags, flexible packages, etc.
Weight Range 0.2kg≤M≤50kg 0.2kg≤M≤50kg
Sorting Capacity 4000 pieces per hour 6000 pieces per hour
Parcel Size Range MAX:1000*1000*700mm (Example for a 1-meter wide device)
MIN:150*150*30mm
Sorting Success Rate 99.99%
Sorting Modes Single-sided sorting / Double-sided sorting
Electric Drum Size Drum length 85mm * Drum diameter 70mm
Conveying Speed 1-1.5m/s 1.2-2m/s
Number of Swing Mechanisms Not less than 2 Not less than 5
Parcel Spacing 800mm 400mm
Operating Noise ≤72dB(A)
Key Features
  • Versatility: Features a flat surface with multiple small electric rollers coated with rubber for flexible contact with various parcel types including clothing, books, boxes, and cartons.
  • Efficient Sorting: Achieves sorting speeds up to 6000 pieces per hour with high load capacity, low noise, and smooth transmission.
  • Compact Structure: Straightforward design ensures stability and low failure rate, with servo motors enabling precise steering adjustments.
  • Quick Installation: Modular design allows for rapid assembly and straightforward maintenance with independently controlled steering modules.
Applications
The swivel wheel sorter is ideal for various logistics environments including:
  • Express delivery services and logistics centers
  • E-commerce warehouses for efficient order processing
  • Manufacturing production lines for material management
  • Industries including healthcare, food processing, and renewable energy
Advantages
  • Advanced Technology: Integrated sensors and servo-driven mechanism ensure fast response times and precise control.
  • Precision Manufacturing: CNC-machined components result in high precision, long lifespan, and low maintenance.
  • Safety and Stability: Designed for durability with comprehensive safety measures meeting industry standards.
  • Reliability: Backed by 17 years of logistics automation expertise with proven durability.
