40/60/80 servo motor kit, 100/400/750W synchronous AC motor, 485 communication drive motor
40/60/80 servo motor kit, 100/400/750W synchronous AC motor, 485 communication drive motor
40/60/80 servo motor kit, 100/400/750W synchronous AC motor, 485 communication drive motor
40/60/80 servo motor kit, 100/400/750W synchronous AC motor, 485 communication drive motor
40/60/80 servo motor kit, 100/400/750W synchronous AC motor, 485 communication drive motor
40/60/80 servo motor kit, 100/400/750W synchronous AC motor, 485 communication drive motor
Specifications
Payment Terms :
L/C,T/T
Certification :
CE
Packaging Details :
carton
Supply Ability :
1000000piece/month
MOQ :
1 piece
Brand Name :
wanhe
Place of Origin :
foshan , china
Model Number :
WH-CE011
Delivery Time :
15-20 days after receive the payment
Price :
usd75~usd98.5
Description

40 series parameters

Motor model

DB40-00330A6-A :0.1

Rated power (KW) : 0.1

Rated voltage (V) :220

Rated current (A) : 1.0

Instantaneous peak current (A): 3

Rated torque (N.m):0.318

Instantaneous peak torque (N.m):0.954

Rated speed (rpm):3000

Peak speed (rpm):6000

Counter-electromotive force (v/1000rpm):22

Torque constant (Nm/A):0.32

Line resistance (Ohms):18.8

Winding (line-to-line) inductance (mH):11.25

Electrical time constant (ms):1.1

Rotor inertia (×10kg·m2):0.066×104

polar number:10

insulation class:F(155°C)


60 series parameters

Motor model

DB40-00330A6-A

Rated power (KW) : 0.2/0.4/0.6

Rated voltage (V) :220

Rated current (A) : 1.7/2.5/4.8

Instantaneous peak current (A): 5.7/7.5/14.4

Rated torque (N.m):0.64/1.27/1.91

Instantaneous peak torque (N.m):1.91/3.81/5.73

Rated speed (rpm):3000

Peak speed (rpm):6000

Counter-electromotive force (v/1000rpm):23/31/25

Line resistance (Ohms):4.57/3.24/1.8

Winding (line-to-line) inductance (mH):4.0/5.8/4.0

polar number:10/10/5

insulation class:F(155°C)


80 series parameters

Motor model

DB80-02430A6-A/DB80-03230A6-A

Rated power (KW): 0.75/1.0

Rated voltage (v): 220

Rated current (A): 4.7/5.8

Instantaneous peak current (A): 14.5/15.6

Rated torque (N.m): 2.39/3.18

Instantaneous peak torque (N.m): 7.17/7.96

Rated speed (rpm): 3000

Peak speed (rpm): 6000

Counter-electromotive force (v/1000rpm): 33/32.5

Torque constant (Nm/A): 0.51

Winding (line-to-line) resistance (Q): 1.09/1.17

Winding (line-to-line) inductance (mH): 4.6/3.9

Number of poles: 10

Insulation level: F (155°C)
