Ku-Band Universal LNB Digital LNB Single LNBF satellite dish Low Noise Block
Ku-Band Universal LNB Digital LNB Single LNBF satellite dish Low Noise Block
Specifications
Brand Name :
SETON
Model Number :
ST-K21WB
Certification :
CE, ISO, ROHS, POP, REACH
Place of Origin :
CHINA
MOQ :
2000pcs
Payment Terms :
T/T,Western Union
Supply Ability :
15 million pieces
Delivery Time :
30-35 days
Packaging Details :
CARTON
Input Frequency Range (Low-Band) :
10.7GHz ~ 11.7GHz
Input Frequency Range (High-Band) :
11.7GHz ~ 12.75GHz
Output Frequency Range (Low-Band) :
950MHz ~ 1950MHz
Output Frequency Range (High-Band) :
1100MHz ~ 2150MHz
Low band LO frequency :
9.75GHz
High band LO frequency :
10.6GHz
Noise figure :
0.7dB (Typ.)/ 1.0dB(Max.)
Conversion Gain :
55dB~65dB/ 60dB (Typ.)
Description
Ku-Band Universal Single LNBF ST-K21WB
  • Input: 10.7~12.75 GHz
  • LO: 9.75 GHz and 10.6 GHz
  • Polarization: Vertical and Horizontal
Technical Specifications


Input Frequency Range

 Low-Band 10.7GHz ~ 11.7GHz
High band 11.7GHz ~ 12.75GHz


Output Frequency Range

 Low-Band 950MHz ~ 1950MHz
High band 1100MHz ~ 2150MHz


LO frequency

 Low-Band 9.75GHz
High band 10.6GHz
Noise figure 0.7dB (Typ.)/ 1.0dB(Max.)
LO Initial Accuracy 0.5MHz
LO Temperature Drift (-30~+60℃) 0.75MHz
LO phase noise @ 1 KHz -75dBc/Hz
LO phase noise @ 10 KHz -80dBc/Hz
LO phase noise @ 100 KHz -90dBc/Hz
Conversion Gain 55dB~65dB/ 60dB (Typ.)
Gain Flatness 3.0dB (Max.)
Gain Variation 0.5dB/26MHz
O/P 1dB Compression Point (P1 dB) 0.0dBm (Min.)
Image-Rejection -40dBc (Min.)
Crosstalk Isolation 20dB (Min.)
O/P VSWR 2.5:1
Control Signals Ca V 10.0V~14.0V
Control Signals Cb H 16.0V~20.0V
Control Signals Cc 22±4KHz
DC-Power 10~20V/100Vdc*mA (Max.)
Output Impedance 75Ω (F-Type)
Working Temperature -30℃~+60 ℃
