Specifications
Brand Name :
Sinowon
Model Number :
DVS-0850
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Payment Terms :
T/T in advance
Supply Ability :
100 sets per month
Delivery Time :
10 days
Packaging Details :
plywood
Optical System :
Parallel optical zoom system
Zoom Objective :
0.8X~5X
Viewing Head :
Binocular head, 20°inclined,Interpupilary distangce 55-75mm
Eyepiece :
Eyepiece for Main Viewing Head 10X/Φ22
Pointer :
Red and Green LED
Illumination :
Optional Ring illumination(LED,fluorescent)
Description

Educational Zoom Stereo Microscope With Built-in Indicator System

DVS-0850 Series Features:

● Adopt the Galilean optical system.

● Can apply for double people observations of the same specimen simultaneously,eliminated the defects of digital teaching.

● The built-in indicator system, display of double color in red and green,can switch as request, convenient to focus the same target.

Specification:

DVS-0850

Optical System

Parallel optical zoom system

Zoom Objective

0.8X~5X

Viewing Head

Binocular head, 20°inclined,Interpupilary distangce 55-75mm

Optional Tilting binocular eyepiece tube, 0-35°inclined, Interpupilary distangce 55-75mm

Objective

Wd:78mm 1X Plan achromatic objective

Optional Wd:276mm 0.3X Achromatic objective

Optional Wd:195mm 0.5X Achromatic objective

Optional Wd:126mm 0.5X Plan apochromatic objective

Optional WD:32.5mm 2X Plan achromatic objective

Eyepiece

Eyepiece for Main Viewing Head 10X/Φ22

Eyepiece for Side Viewing Head 10X/Φ22

Pointer

Red and Green LED

Illumination

Optional Ring illumination(LED,fluorescent)

Working Distance

78mm

Focusing Range

215mm

Base Stage

420mm×350mm

Toughened glass
stage

250mmx250mm

Optional
Accessories

Coaxial illumination

Epi-fluorescent attachment

Iris diaphragm

Beamsplitter(one port)

Beamsplitter(two ports)

Photography & video attachment

Micrometter

LCD Attachment

Dimension:

Educational  Zoom Stereo Microscope With Built-in Indicator System
