warranty 1 Year machine type Spray Booths, Painting Equipment, Pre-treatment Equipment, Conveying Equipment, Drying Oven, Curing oven, Coating Equipment type Coating Production Line voltage 380V or Customizable coating Vacuum Coating core components PLC, Pressure vessel, Gear, Pump, vacuum machine chamber video outgoing-inspection Provided machinery test report Provided key selling points Free training/easy to operate substrate Stainless steel power(w) 150KW-500KW or Customizable weight (kg) 50000 place of origin Guangdong, China brand name Lion King dimension(l*w*h) L4500mm*W5000mm*H3000mm or customizable After-sales Service Provided Engineers available to service machinery overseas Chamber material STAINLESS STEEL Coating application/coating substrate metal , glass and plastic products Raw coating material Titanium , chrome, Aluminum, Brass, Zirconium,etc. ultimate vacuum 5*10-4 pa Coating color Golden, rose golden, black, dark black,champagne, Brown,etc. Coating technology Multi arc ion pvd coating technology Installation and training Free oversea installing and training service Control mode PLC+HMITouch screen+Full automatic +Alarm system , Full Automatic Vacuum system Diffussion pump+roots pump+rotary vacuum pump Packaging and delivery Packaging Details Plastic film cover & wooden box high cube export standard packing container for CICEL Stainless Steel Barrier Multi-Arc Ion PVD Vacuum Coating Machine Port of dispatch Guangdong Selling Units Single item Single package size 80X25X25 cm Single gross weight 10.000 KG Packaging examples High Precision E-BEAM Optical Coating Equipment The precision vacuum coating machine for forming high precision optical multilayer film on glass / PC / PMMA substrate; the combination of various components to meet the customer's needs can form the film with better quality; the umbrella frame of substrate adopts the central rotation mode to reduce the vibration and particles, so that the substrate can rotate stably. The multi-layer film can be stably formed by using the electron beam heating method without electrode on the crucible as the evaporation source; the high-precision and stable optical multi-layer film can be formed by adopting the unique ratio control method and multi-point online monitoring of the company; the base umbrella frame can be taken out by using the elevator with good operability. Using the ion source with uniform distribution and high ion current density, equipped with double electron beams, the multi-point and ring crucible can be plated with more than 100 layers. The automatic evaporation process is realized by using the automatic evaporation control system, and the workpiece frame can be bell type or planetary type. Precision optical lens AR PVD vacuum deposition coating system can coat multi-layers,transparent color,anti-finger print film,anti-scatch film Deposit material including: TiO2,Ti3O5,H4,ZrO2,ZNS,Al2O3,Mgf2,SIO2,Au,Ag,Cu,Ti,Sn Application: AR,AF,Hard AR coating,enhanced reflection coating,band pass filter,rgb filter,HR coating,Photocatalyst,Dielectric Mirror,IR cut off filter. Precision optics PVD vacuum coating machine is a flexible platform for fast, precise and fully automated thin film coatings. It specializes in high quality optical coatings featuring very low absorption and scattering. Unsurpassed optical performance is ensured by the extremely dense, smooth, stoichiometric, and amorphous layers. Ultimate precision in layer growth control is facilitated by an optical monitoring system for in-situ on-substrate measurements. Why optical vacuum metalizing? Optical coaters produce AR,mirrow and top coatings on all lens materials via proven thermal evaporation process (PVD),guaranteeing the utmost level of quality Powerful pump system enables fast pump-down, Extremely fast technology with unprecedented low process times Ion-assisted optimized deposition for best layer adhesion and hardness Offers consistent AR coatings and highest lens productivity Touch screen and user-friendly control software for easy job and process set-up and change User friendly control software Environment friendly Applications Mineral glass optical lens Polymer optical lens (CR 39, PC...) Camera lens Optical filte Polycarbonate Acrylic Photochromic Supply capacity Supply Ability 10 sets per Month Stainless Steel Barrier Pvd Vacuum
