Specifications
Brand Name :
OSMANUV
Model Number :
Specification
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
Negotiation
Delivery Time :
15 days
Packaging Details :
WOOD PACKAGING
Loading Weight :
Customize
Operating Temperature :
-10°C to 50°C
Z Accuracy :
0.004mm
Belt Color :
blue, white, green for choice
Transmission Band Width :
650mm
Voltage :
220V
Weight :
150 kg
Belt Length :
3000mm
Description
Product Overview

This conveyor system is engineered for efficient, reliable transport of products, components, and bulk materials across manufacturing, packaging, warehousing, and logistics environments. Available in belt, roller, chain, slat, or modular plastic configurations, the system supports straight, inclined, declined, or curved paths.

The conveyor is highly customizable in dimensions, speed, material, and automation level to integrate seamlessly into new or existing production lines. Ideal for food, automotive, electronics, pharmaceutical, and e-commerce industries.

Technical Parameters
Parameter Standard Specification Customizable Options
Conveyor type Belt conveyor Yes - roller / chain / slat / modular plastic / magnetic / vacuum
Conveyor length 3000 mm (standard section) Yes - any length from 500 mm to 50+ meters
Conveyor width 400 mm Yes - 100 mm to 2000 mm
Belt/roller material PVC belt (green) Yes - PU / silicone / rubber / steel roller / plastic roller
Frame material Carbon steel (painted RAL7035) Yes - SS304 / SS316L / anodized aluminum
Load capacity 50 kg/m Yes - 10 kg/m to 500 kg/m (or 2000 kg per pallet)
Conveying speed 0-15 m/min (fixed) Yes - 0-30 m/min with VFD / servo motor
Incline angle 0° (horizontal) Yes - up to 45° (with cleated belt or pocket chain)
Motor power 0.37 kW Yes - 0.12 kW to 7.5 kW
Power supply 380V / 50Hz / 3-phase Yes - 110V / 220V / 415V / 60Hz / 1-phase
Operating temperature -5°C to +50°C Yes - high-temp (+200°C) / low-temp (-30°C)
Applications
  • Manufacturing assembly lines - automotive, appliance, electronics, machinery
  • Packaging & filling - bottle, carton, bag, can conveying
  • Warehousing & logistics - sorting, merging, diverting, accumulation
  • Food processing - stainless steel washdown conveyors (customizable for wet environment)
  • Pharmaceutical & cleanroom - customizable with static-free belt and sealed frame
  • E-commerce fulfillment - telescopic belt conveyor for truck loading/unloading
  • Mining & heavy industry - customizable impact bed and heavy-duty rollers
  • Airport baggage handling - customizable curved and merging sections
Customization Options

This conveyor system is fully customizable to your exact application requirements:

  • Dimensions - Customizable length, width, and height (including floor-to-floor incline)
  • Belt type - Customizable: smooth grip / chevron cleat / sidewall / wire mesh / chain slat
  • Drive position - Customizable: end drive / center drive / top drive / bottom drive / drum motor
  • Side guides - Customizable height, material (nylon / stainless steel / UHMW)
  • Stand configuration - Customizable fixed height, adjustable legs, or mobile casters
  • Control system - Customizable: simple on/off, VFD speed control, PLC integration (Profibus / Ethernet IP / Modbus)
  • Safety features - Customizable: emergency pull cord, belt misalignment switch, slip monitor
  • Color - Customizable any RAL code + branded powder coating
  • Environment adaptation - Customizable: waterproof (IP65/IP69K), explosion-proof (ATEX), cleanroom (ISO 5-8)
Key Features
  • Modular design - easy to extend, shorten, or reconfigure
  • Low maintenance - sealed bearings and wear-resistant belt (customizable self-lubricating chain)
  • Quiet operation - < 70 dB at full speed (customizable noise-reduction enclosure)
  • Anti-static option - for electronics and explosive environments (customizable)
  • Accumulation capability - zero-pressure or minimum-pressure accumulation (customizable sensor layout)
  • Quick belt change - hinged frame design on selected models (customizable tool-less access)
  • Energy efficient motor - IE3 / IE4 class (customizable with energy feedback drive)
Support and Services
  • Layout design assistance - free CAD drawing for your line integration (customizable revision limits)
  • Installation guidance - video + manual (customizable on-site supervision available)
  • Remote support - 24/7 via WhatsApp / WeChat / TeamViewer (customizable SLA response time)
  • Spare parts - available for 10+ years (customizable recommended parts kit upon order)
  • Preventive maintenance contract - customizable frequency (monthly / quarterly / annually)
  • Training - operator + technician training (customizable duration: 1-5 days / on-site or remote)
  • Warranty - 18 months standard (customizable extended to 24-36 months)
Packing and Shipping
Packing Method
  • Belt/rollers wrapped in stretch film with anti-rust oil
  • Frame disassembled into sections for container loading
  • Plywood cases for control panel and motor (customizable with shock indicators)
  • Customizable with pallet jack pockets for easy unloading
Shipping Terms

FOB / CIF / EXW / DAP / DDP (customizable port: Shanghai / Ningbo / Shenzhen / Qingdao / Tianjin)

Lead Time
  • Standard conveyor (existing design): 10-15 working days
  • Fully customized system: 20-35 working days
  • Customizable rush order: +20% for 10-day delivery
Container Loading

20GP / 40GP / 40HQ (customizable loading plan provided)

Frequently Asked Questions
Q1: What is the maximum conveyor length for a single drive?

A: It depends on belt type and load. Standard belt conveyor: up to 30 meters. For longer lengths, we offer customizable multi-drive or intermediate drive configuration.

Q2: Can I get a curved conveyor?

A: Yes. We offer customizable curved belt conveyors (30°, 45°, 60°, 90°, 180°) and chain conveyors with any turning radius.
