Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Specifications
Type :
Laminating Machine,Factory Fully Automatic Film Thermal Laminating Machine
Power :
12kw,50kw,3KW,2.5KW,220V 50Hz
Product name :
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Condition :
New
Brand Name :
OSMANUV
Model Number :
OSM-FM-1320
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
Negotiation
Delivery Time :
40 days
Packaging Details :
WOOD PACKAGING
Warranty :
1 Year
Voltage :
380V,220V,220V/110V,380V/50HZ,380V/220V
Application :
Machinery & Hardware,Commodity,Medical,Chemical,Food
Description
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Production Line Overview

This automated film laminating production line specializes in applying wear-resistant decorative films to various furniture boards (MDF, particle board, plywood). It ensures perfect film adhesion with scratch and stain resistance, making it ideal for high-quality furniture manufacturing.

Line Composition
  • Automatic board loading/unloading system
  • Surface pretreatment unit (cleaning/plasma treatment)
  • Precision adhesive application system
  • High-pressure film laminating unit
  • CNC trimming and edge finishing system
  • Quality inspection with vision system
  • Centralized PLC control with IoT connectivity
Technical Specifications
Parameter Category Specification Notes
Max. Board Width 0-1320 mm Customizable to specific requirements
Production Speed 1-20 m/min Adjustable based on material
Laminating Accuracy ±0.15 mm Laser guiding system
Operating Pressure 50-150 tons Customizable pressure settings
Temperature Control 50-200°C ±1°C PID precision control
Power Requirement 380V/50Hz/100kW Customizable voltage options
Applications
  • Office furniture manufacturing
  • Kitchen cabinet production
  • Wardrobe and storage systems
  • Commercial furniture applications
Customization Options
  • Width Options: Customizable from 600mm to 2800mm
  • Film Compatibility: Adaptable for PVC, PP, PET, decorative films
  • Automation Level: From semi-auto to fully robotic systems
  • Special Features: Optional embossing or texture patterns
Key Features
  • High Efficiency: Automatic feeding and stacking systems
  • Precision Control: CNC-controlled temperature and pressure
  • Quality Assurance: Integrated vision inspection system
  • Energy Saving: Heat recovery system reduces energy consumption
Support & Services
  • Installation and commissioning supervision
  • Comprehensive operator training
  • 24/7 technical support with remote monitoring
  • 18-month warranty on main components
Packaging & Shipping
  • Heavy-duty export packaging
  • Weatherproof wooden crates
  • Professional logistics planning
  • Worldwide shipping available
Frequently Asked Questions
What is the minimum order quantity?
We provide customizable solutions from single machines to complete production lines.
Can the line handle different board materials?
Yes, the system is customizable for MDF, particle board, plywood, and other substrates.
