Specifications
Brand Name :
OSMANUV
Model Number :
Specification
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
Negotiation
Delivery Time :
30-45 days
Packaging Details :
WOOD PACKAGING
Material :
Pulp
Coating Means :
DOD Inkjet Heads
Heating Source :
Electric IR Heating
Coating Area :
Large Area
Heating Method :
Electric
Coating Thickness Control :
Adjustable
Dimension :
As customer requirement
Model :
OSM-XT-450T
Production Line Integration :
Can be integrated into pulp molding production line
Description
Compact 24-Position Rotary Spin Coater | Customizable Substrate Sizes & Spin Programs for R&D and Pilot Production
Product Overview

This 24-station spin coater is designed for high-throughput thin-film deposition of photoresist, polymers, nanoparticles, and sol-gel materials. Each station operates independently or synchronously. The system supports customizable spin profiles (acceleration, duration, speed) for each station, making it ideal for both R&D and production environments.

Technical Specifications
Parameter Value / Range Customization Option
Number of stations 24 ✔ Customizable (16/24/32 stations)
Substrate size Up to 12" wafer or 300×300 mm panel ✔ Customizable chuck size
Spin speed range 100 - 12,000 rpm ✔ Programmable per station
Speed accuracy ±1 rpm -
Acceleration range 100 - 10,000 rpm/s ✔ Adjustable per recipe
Spin time range 1 - 999 sec / step ✔ Customizable steps
Dispense volume 0.1 - 20 mL per nozzle ✔ Customizable nozzle type
Motor type Brushless DC servo -
Coating uniformity ±3% (across 24 stations) ✔ Upgradable to ±1%
Exhaust flow 150 - 500 m³/h ✔ Customizable exhaust interface
Power supply 220V / 50-60 Hz / 3.5 kW ✔ Customizable voltage
Dimensions (L×W×H) 1800×1200×900 mm ✔ Customizable footprint
Weight 520 kg -
Applications
  • Semiconductor wafer coating (photoresist)
  • OLED & perovskite solar cell fabrication
  • Bio-chip & polymer film preparation
  • Anti-reflective coating for optics
  • Nanomaterial deposition (graphene, quantum dots)
  • R&D multi-condition screening (24 different parameters simultaneously)
Customization Options

We offer full customization:

  • Station count: 8 / 12 / 16 / 24 / 32 stations
  • Substrate shape & size: round wafers, square panels, irregular substrates
  • Dispense system: single-needle, multi-nozzle, spray, or inkjet
  • Environment control: humidity, temperature, particle filtration
  • Automation level: manual load, semi-auto, full inline integration
  • Software: customized recipe structure, barcode scanning, data export to MES
Key Features
Individual station control with independent spin motors
Touchscreen with recipe library (up to 999 recipes)
Real-time speed & time monitoring per station
Anti-drip vacuum detection for substrate hold
Automatic solvent dispenser sync
Low vibration and acoustic enclosure
Emergency stop and interlock protection
Customizable exhaust and waste collection tank
Support and Services
  • Installation and on-site training
  • 18-month standard warranty (extendable)
  • Remote debugging and IoT support option
  • Annual calibration and preventive maintenance plan
  • Spare parts supply for ≥10 years
  • Custom software development support
Packing and Shipping
  • Packing: Anti-static vacuum-sealed + plywood export case (shock-proof, moisture-proof)
  • Shipping method: FOB / CIF by sea, air (express optional for benchtop units)
  • Lead time: 30-45 working days after order confirmation (customization adds 15 days)
  • Documents included: User manual, calibration certificate, CE declaration
Frequently Asked Questions
Q1: Can the 24 stations run different spin programs simultaneously?
A: Yes. Each station supports a customizable independent recipe (speed, time, acceleration).
Q2: What substrate sizes can I customize?
A: From 5×5 mm chips to 300×300 mm panels or 12" wafers. Please provide your substrate drawing.
Q3: Is this machine cleanroom compatible?
A: Yes. Class 100 (ISO 5) compatible with optional HEPA/ULPA filter module.
