Baby Stroller Lifting and Pressing Testing Machine
Baby Stroller Lifting and Pressing Testing Machine
Baby Stroller Lifting and Pressing Testing Machine
Baby Stroller Lifting and Pressing Testing Machine
Baby Stroller Lifting and Pressing Testing Machine
Baby Stroller Lifting and Pressing Testing Machine
Specifications
Brand Name :
Dongjun
Model Number :
DJ-26-26
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500pcs
Delivery Time :
15-25Work days
Packaging Details :
Wooden crate packaging
volume :
160×110×190cm
Test count :
0-99999999 times
bear load :
MAX 50 pounds
test power supply :
AC220V 50HZ
Description

Baby Stroller Lifting and Pressing Testing Machine

Product Overview:

This machine is suitable for conducting lift-and-press durability tests on push-type baby strollers when simulating obstacle surmounting. The test method is as follows: place a model baby in the stroller, lift the stroller until its rear wheels are 150 mm off the ground during lifting, and press it down until its front wheels are 150 mm off the ground during pressing. The test shall be performed at a frequency of 15±1 cycles per minute for 3000 consecutive reciprocating tests. After the test, visually inspect the stroller for any damage. The machine will automatically stop operation once the set number of cycles is reached.


Meet the standard:


AS/NZS2088:2000 ASTM-F833

CNS6263-11,BSL-1996,EN1888.2003




Parameters

Parameter Item

Specification

Test stroke

150mm

volume

160×110×190cm

Drive mode

Pneumatically driven
Vertical adjustment of distance
MAX400mm

Test count

0-99999999 times

bear load


MAX 50 pounds

test power supply

AC220V 50HZ

Experimental work

Single-seat vehicle body

Machine weight

Approximately 250KG


Baby Stroller Lifting and Pressing Testing Machine



This equipment adopts a high-strength steel structure frame, which has undergone precision welding and aging treatment, resulting in extremely high body stability. It can effectively avoid the impact of equipment vibration and deformation on detection accuracy. It is also equipped with multiple safety protection devices (emergency stop button, overload protection, limit protection), which can prevent potential safety hazards such as component falling off and equipment failure during testing, and ensure the safety of operators and test samples.



Equipment Features

  • It adopts pneumatic drive, ensuring stable and reliable operation, with a test stroke of 150 mm and a maximum vertical adjustment distance of 400 mm, enabling flexible adjustment.
  • Large counting range from 0 to 99999999 times, with a maximum load capacity of 50 pounds, meeting the requirements for long-term durability testing
  • Designed specifically for testing single-seat vehicle bodies, it is compatible with a standard AC220V 50Hz power supply. The machine dimensions are 160×110×190cm, with a weight of approximately 250kg and a stable structure.

Baby Stroller Lifting and Pressing Testing Machine

Baby Stroller Lifting and Pressing Testing MachineBaby Stroller Lifting and Pressing Testing Machine

Company Profile

Baby Stroller Lifting and Pressing Testing Machine

PACKING AND TRANSPORTATION

Baby Stroller Lifting and Pressing Testing Machine

Baby Stroller Lifting and Pressing Testing Machine

FAQ

How to install and use the product?

The product is shipped with an operating instructions and video of English version.or we will send you an operation video to teach you how to install and use the product with English speaking. However, if you need us to teach you face to face, please let us know in advance.

How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
