Baby Carrier Dynamic Strength Tester
Baby Carrier Dynamic Strength Tester
Baby Carrier Dynamic Strength Tester
Baby Carrier Dynamic Strength Tester
Baby Carrier Dynamic Strength Tester
Baby Carrier Dynamic Strength Tester
Specifications
Brand Name :
Dongjun
Model Number :
DJ-ET008
Certification :
ISO9001，CE，
Place of Origin :
Dongguan, China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500pcs
Delivery Time :
15-25Work days
Packaging Details :
Wooden crate packaging
Test load :
0–15 kg (adjustable standard counterweight)
Vibration stroke :
50–200 mm continuously adjustable
Vibration frequency :
1–5 Hz (60–300 times/minute)
Counting range :
0–999,999 times, automatic stop
Control method :
PLC touch screen + servo drive
Applicable standards :
EN 13209, ASTM F2236, GB 31701
Description

Baby Carrier Dynamic Strength Tester

Product use
Baby Carrier Dynamic Strength Tester is a specialized testing device designed to evaluate the dynamic strength, durability, safety and structural stability of baby carriers, baby slings, hip seats and infant carrying products. It uses a simulated baby model or standard test weight to mimic actual wearing, shaking, bouncing and carrying movements. Under the set frequency, force, amplitude and test cycles, the machine applies repeated dynamic force to test the strength of straps, buckles, stitching, fabric and connecting parts. It can monitor deformation, breakage, cracking or failure in real time and stop automatically when abnormalities occur. The equipment provides reliable test data to verify product safety performance and compliance with relevant safety standards. It is widely used in baby product manufacturing, quality inspection centers, laboratories and certification institutions to ensure the safety and reliability of infant carriers during daily use.

Parameters


Counter
0-999.9 times/min
Tachometer 0-999.9 times
Testing Speed 120 times/minute; Amplitude: 120 mm
Power Supply AC220V.50HZ; Power: 1KW
Body Material Rigid material
Overall Machine Dimensions Approximately 1000*800*1500mm
Extra-large Floor Mat Feet (Because the machine may shift during vibration)
PLC Control Panel PLC Control Panel: Aluminum alloy frame + stainless steel accessories

Baby Carrier Dynamic Strength Tester

The Baby Carrier Testing Machine

This Baby Carrier Testing Machine is a professional testing device used to evaluate the durability, strength, safety and reliability of baby carriers, baby slings, hip seats and other infant carrying products. It simulates actual daily use conditions such as oscillation, swing, pulling and loading to test the structural stability, stitching fastness, buckle strength and overall fatigue resistance.

Baby Carrier Testing Machine

This Baby Carrier Testing Machine is a specialized durability and safety testing instrument designed for baby carriers, baby slings, hip seats, wraps and other infant carrying products. It is used to simulate long-term actual wearing, walking, swinging, lifting and vibration conditions, so as to evaluate the structural strength, stitching fastness, buckle reliability, strap tension resistance and overall fatigue performance of the product.

Baby Carrier Dynamic Strength Tester

Company Profile

Baby Carrier Dynamic Strength Tester

PACKING AND TRANSPORTATION

Baby Carrier Dynamic Strength Tester

Baby Carrier Dynamic Strength Tester

FAQ

How to install and use the product?

The product is shipped with an operating instructions and video of English version.or we will send you an operation video to teach you how to install and use the product with English speaking. However, if you need us to teach you face to face, please let us know in advance.

How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
