Core Functions and Technical Advantages

1. Mesh Belt Conveyor System: Continuous Operation for Efficient Batch Processing
   Stainless Steel Mesh Belt Transmission:

• Variable frequency speed regulation (0.5 - 2m/min) adapts to workpieces of different sizes (maximum load capacity of 10kg/m²), supporting 24 - hour continuous operation;
• Anti - jamming photoelectric induction devices monitor the position of workpieces in real - time to avoid collisions and stacking. It is compatible with special - shaped structural parts such as flanges, gears, and stamping parts.
  Open - type Tank Layout: The cleaning area and the air knife drying area are independently partitioned. The through - type mesh belt design reduces manual intervention, and the processing time for a single batch of workpieces is 30% shorter than that of traditional single machines.

2. Synergistic Cleaning of Ultrasonic and Spraying: Full - Dimensional Stain Removal
   50KHZ Medium - Frequency Ultrasonic Assistance (Cleaning Tank):

• The diameter of cavitation bubbles is approximately 30 - 50μm, effectively loosening stubborn stains such as residual cutting fluids and polishing compounds in the blind holes and threaded gaps of metal parts;
• Working in conjunction with the spraying system, it improves the cleanliness of complex structural parts, especially suitable for small and medium - sized workpieces such as screws and bearings.
  High - Pressure Spraying Scouring:
• Three sets of spraying arms with a pressure of 50bar are arranged at 45° angles, scouring the surface of workpieces without dead angles. Combined with 70°C hot pure water (adjustable), it quickly dissolves oily pollutants;
• The magnetic filter (with a precision of 50μm) intercepts impurities in real - time, prevents secondary pollution of the circulating liquid, and extends the service life of the cleaning liquid by 20%.

3. Air Knife Drying Technology: Quick Drying without Watermarks
   Dual Air Knife Drying System (Air Knife Area):

• Constant - temperature hot air at 80°C (with an accuracy of ±5°C) combined with high - speed airflow (wind speed ≥20m/s) blows off the residual water on the surface of workpieces within 5 seconds, avoiding watermarks left by traditional drying methods;
• The air volume is intelligently adjusted, automatically matching drying parameters according to the material of the workpiece (metal/plastic) to prevent high - temperature deformation of plastic parts.
