BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment
BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment
BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment
BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment
BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment
BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment
Specifications
Brand Name :
UCHI
Model Number :
BLDC 4820
Certification :
Completed
Place of Origin :
Dongguan China
MOQ :
1000PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs stcoks
Delivery Time :
5-7 days
Packaging Details :
Standard
NO LOAD VOLTAGE :
24.04V
SPEED AT EFF MAX :
3387RPM
certificate :
3C
Pout max :
60.19W
TORQUE MAX :
305.3mN.m
Description
BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment

Typical Applications:

1. Home Application

2. Business Equipment

3. Medical Apparatus

4. Industry Apparatus

BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment

Brushless Motor Technical Data

Point VOLTAGE CURRENT INPUT POWER SPEED TORQUE

OUTPUT POWER

 EFFICIENCY TIME
V A W RPM mN.m W % S
NO LOAD 24.04 0.167 4.023 3904 2.6 1.055 26.2 0.000
EFF MAX 23.99 1.007 24.16 3387 60.6 21.49 89.0 22.66
POUT MAX 23.81 3.838 91.37 2312 248.7 60.19 65.9 35.89
TORQUE MAX 23.56 5.613 132.2 1830 305.3 58.50 44.2 39.50
END 23.56 5.613 132.2 1830 305.3 58.50 44.2 39.50

Features:

1. High Efficiency: BLDC 4820 motors can achieve high efficiency levels, often up to 78.41% at their maximum efficiency point. This is due to the absence of mechanical brushes, which reduces energy losses.

2. Low Noise: These motors operate smoothly with minimal noise, making them ideal for applications that require a quiet operating environment.

3. Long Lifespan: With no brushes to wear out, BLDC 4820 motors have a significantly longer lifespan compared to brushed motors. They can operate reliably for over 3000 hours.

4. High Torque: Despite their compact size, these motors can deliver strong torque, making them suitable for demanding tasks such as drilling and cutting.

BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment

BLDC 4820 Brushless Motors For Medical Apparatus And Business Equipment
