High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm
Specifications
Brand Name :
Heling Machine
Model Number :
M12-160U
Certification :
10221508
Place of Origin :
CHINA
MOQ :
1pcs
Price :
Welcome to Inquire
Payment Terms :
T/T
Supply Ability :
20+SET+PER month
Delivery Time :
30-60 Work days
Packaging Details :
wooden box
Name :
U Bolt Making Machine
After-sales service provided :
Online support,Video technical support
Core components :
Bearing, motor, pump
Usage :
After the wire is input, it is automatically formed, threaded, and precisely cut, efficiently producing finished U-bolts.
Warranty :
1 Year
Voltage :
380V/440V/415V,50HZ/60HZ
Core selling points :
Easy to operate, long service life, high productivity, patented product, automatic, multi-functional, high precision
Package :
wooden case
Color :
Customizable
Description
Multi-spec Small U-bolt Machine – Rapid Mold Changeover
Feature:

Micro-spec Precision Positioning
Optimized for ultra-small U-bolts (minimum diameter Φ3mm, length 20mm), with dual-axis servo positioning system ensuring no offset during bending/thread rolling, meeting high-precision electronics industry requirements.
Automatic Counting & Defect Sorting
Integrated photoelectric counting sensor and quality inspection module, accurately counting finished products (error ≤0.1%) and automatically separating defective pieces, eliminating manual sorting labor.
Low-temperature Processing Protection
Built-in cooling system controls processing temperature ≤80℃, avoiding material softening or deformation for heat-sensitive materials (e.g., thin stainless steel, copper wire), ensuring mechanical properties of small workpieces.
Portable & Movable Design
Equipped with heavy-duty universal wheels and locking mechanism, easy to move between workshop stations (net weight ≤300kg), adapting to flexible production layout changes for small factories.

Specification:
Model

Max.Thread Diamete

(mm)

Max.U-Bolt Blank Length

(mm)

Main Motor(KW)

Straighten The Motor(KW)

Froming Motors(KW)

Weight

(KG)

Capacity

(PCS/mm)

Volume(L*W*H)(m)
M5-60U 5 60 4 1.5 1.5 1400 70-90 2.8*1*1.8
M6-70U 6 70 5.5 2.2 2.2 1500 70-90 2.35*1.05*1.67
M6-150U 6 150 5.5 2.2 2.2 1600 70-90 2.45*1.05*1.67
M8-80U 8 80 7.5 3 3 2000 50-70 2.9*1.1*1.85
M8-150U 8 150 11 3 3 2400 50-60 3*1.1*1.85
M8-200U 8 200 11 3 3 2500 50-60 3*1.1*1.85
M10-80U 10 80 7.5 3 3 2100 50-60 3.0*1.1*1.85
M10-130U 10 130 11 3 3 2900 50-70 3.1*1.1*1.8
M12-160U 12 120 18.5 4 4 3600 50-60 3.3*1.3*2.2
M12-200U 12 200 18.5 4 4 3800 50-60 3.3*1.3*2.2
M14-200U 14 200 22 5.5 5.5 4300 40-50 3.5*1.3*2.35
M16-200U 16 200 30 7.5 7.5 6800 40-50 4.2*1.9*2.6
Description:

High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm

High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm

High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm

High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm

High Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mmHigh Speed U Bolt Making Machine Multifunctional For Ultra Small U Bolts 20mm–100mm

Advantage:

High-speed Small U-bolt Making Machine (20–100mm Length

Factory Showcase:

Exhibition:
