Specifications
Brand Name :
Heling Machine
Model Number :
M12-600
Certification :
10221508
Place of Origin :
CHINA
MOQ :
1pcs
Price :
Welcome to Inquire
Payment Terms :
T/T
Supply Ability :
20+SET+PER month
Delivery Time :
30-60 Work days
Packaging Details :
wooden box
Product Name :
U Bolt Making Machine
Voltage :
380V/440V/415V,50HZ/60HZ
Usage :
After the wire is input, it is automatically formed, threaded, and precisely cut, efficiently producing finished U-bolts.
Warranty :
1 Year
Core components :
Bearing, motor, pump
Core selling points :
Easy to operate, long service life, high productivity, patented product, automatic, multi-functional, high precision
After-sales service provided :
Online support,Video technical support
Package :
wooden case
Color :
Customizable
Precision :
±0.1 mm
Productioncapacity :
100-200 pieces per hour
Applicable Bolt Diameter :
6mm - 20mm
Operatingmode :
Semi-automatic/Automatic
Motorpower :
5.5kW
Machine type :
Automatic
Power supply :
220V / 380V
Installationtype :
Floor-mounted
Dimensions :
2000mm x 1500mm x 1800mm
Weight :
1500 kg
Coolingsystem :
Water cooling
Material :
Steel
Name :
U Bolt Making Machine
Description

Custom U Bolt Making Machine for Manufacturing Square Round and Special Shaped U Bolts with Mold Service

Feature:

1. High-efficiency Mass Production, Strong Capacity
Produces 8–60 pieces per minute for standard workpieces; 12–15 pieces per minute for large-spec U-bolts, meeting large-scale production demands.
2. Precision Machining, Consistent Quality
Features ±0.05mm dimensional accuracy and uniform thread rolling, ensuring all finished U-bolts meet strict industry standards.
3. Full Automation, Labor Cost Reduction
Integrates automatic feeding, bending, thread rolling and discharging, requiring only 1 operator for monitoring and reducing labor input by 60%.
4. Multi-spec Adaptability, Flexible Production
Compatible with U-bolts of different diameters (M6–M30) and lengths (50–500mm); quick die change within 10 minutes for diverse orders.


Specification:

Model

Range of manufacturable

diameters

(mm)

Customizable length range

(mm)

Weight

(KG)

Capacity

(PCS/mm)
M6 4-6 70-200 1500-2800 40-65
M8 5-8 80-300 2000-3100 40-60
M10 6-10 130-500 2900-4200 25-60
M12 8-12 160-800 3700-11000 25-55
M14 10-14 200-800 4300-12000 25-55
M16 12-16 200-800 6800-13500 25-50
M20 16-20 400-800 12500-18000 25-45
M24 18-24 400-1000 13500-21000 20-40
M27 20-27 400-1000 1400-23000 15-35


Description:

Custom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / AutomaticCustom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / AutomaticCustom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / AutomaticCustom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / AutomaticCustom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / AutomaticCustom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / AutomaticCustom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / AutomaticCustom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / Automatic


Advantage:

Full Automation & Labor Cost Optimization
Integrates automatic feeding, bending, thread rolling and discharging in one line; only 1 staff is needed for supervision, cutting labor costs by 60% compared with semi-automatic models.

Factory Showcase:

Custom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / Automatic

EtiExhibition:

Custom U Bolt Making Machine 5.5kW 220V 380V Semi Automatic / Automaticon
