Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
Specifications
Brand Name :
Heling Machine
Model Number :
M12-200Z
Place of Origin :
CHINA
MOQ :
1pcs
Price :
Welcome to Inquire
Payment Terms :
T/T
Supply Ability :
80+SET+PER month
Delivery Time :
30-40 Work days
Packaging Details :
wooden box
Name :
Thread Rolling Machine
Voltage :
380V/440V/415V,50HZ/60HZ
After-sales service provided :
Online support,Video technical support
Core components :
Bearing, motor, pump
Warranty :
1 Year
Core selling points :
Easy to operate, long service life, high productivity, patented product, automatic, multi-functional, high precision
Usage :
Efficient Automation Fully automatic continuous operation, integrating multiple processes such as straightening, cutting, forming, and thread rolling, significantly improving production efficiency and reducing labor costs. Precision and Reliability Adoptin
Package :
wooden case
Color :
Customizable
Description
Budget-friendly Industrial Thread Rolling Machine with Stable Precision


Key Features

Excellent Workmanship & Manufacturing Process
Machine body adopts integral casting and CNC machining. Core thread rolling wheels are processed by carburizing and quenching, with surface roughness Ra ≤0.8μm for stable overall performance.
Low Defect Rate
Optimized pressure control structure effectively reduces workpiece deformation and thread slipping. The overall defective rate is kept below 0.2%, which helps save raw material consumption.
Wide Specification Adaptability
Compatible with wire diameters Φ3–Φ16mm and thread types including metric, inch and UNF. It is suitable for most production requirements of industrial fasteners.
Dual-mode Operation (Semi/Full Automatic)
Supports semi-automatic trial production and full-automatic mass production, with a stable output of 60–120 pieces per minute to meet normal production arrangement.

Technical Specifications
Model Max.Thread Diameter(mm) Max.Length(mm) Motor(kw) Capacity (PCS/mm) Volume(L*W*H)(m) Weight(kg)
M5-65Z 5 65 3 120-140 1.50*1.30*1.10 975
M6-70Z 6 70 4 80-100 1.60*1.60*1.35 1040
M6-120Z 6 120 4 80-100 1.60*1.60*1.35 1300
M8-80Z 8 80 4 80-100 1.74*1.36*1.20 1400
M10-130Z 10 130 11 70-90 2.00*1.48*1.30 2000
M12-200Z 12 200 18.5 40-50 2.45*1.60*1.45 3100
M14-200Z 14 200 22 30-40 2.50*1.65*1.50 4800
M16-150Z 16 150 30 30-40 2.80*2.10*1.70 5500
M16-300Z 16 300 30 30-40 2.80*2.10*1.75 6000
Product Overview

Budget Friendly Thread Rolling Machine Automation Easy Operate

Budget Friendly Thread Rolling Machine Automation Easy Operate

Budget Friendly Thread Rolling Machine Automation Easy Operate

Budget Friendly Thread Rolling Machine Automation Easy Operate








Competitive Advantages

Low Operation & Maintenance Costs
Energy-saving motor (25% less power) + minimal routine maintenance (only lubrication) cut daily expenses.

Manufacturing Excellence
Budget Friendly Thread Rolling Machine Automation Easy Operate
Budget Friendly Thread Rolling Machine Automation Easy Operate
