Specifications
After-sales service provided :
Online support,Video technical support
Name :
Thread Roll Machine
Usage :
Efficient Automation Fully automatic continuous operation, integrating multiple processes such as straightening, cutting, forming, and thread rolling, significantly improving production efficiency and reducing labor costs. Precision and Reliability Adoptin
Brand Name :
Heling Machine
Place of Origin :
CHINA
MOQ :
1pcs
Price :
Welcome to Inquire
Payment Terms :
T/T
Supply Ability :
80+SET+PER month
Delivery Time :
30-40 Work days
Packaging Details :
wooden box
Model Number :
M16-150Z
Color :
Customizable
Core components :
Bearing, motor, pump
Voltage :
380V/440V/415V,50HZ/60HZ
Package :
wooden case
Core selling points :
Easy to operate, long service life, high productivity, patented product, automatic, multi-functional, high precision
Warranty :
1 Year
Description
Stable-quality Thread Rolling Machine – Factory Price for Industrial Applications


Key Features

Low Noise & Vibration
Shock-absorption base + precision gear transmission; operating noise ≤72dB (meets workshop environmental standards).
One-key Parameter Recall
Saves 15 groups of process parameters; shortens startup preparation time to 5 minutes.

Top-tier Workmanship & Craftsmanship
Machine body adopts integral casting + CNC machining; core thread rolling wheels undergo carburizing quenching, surface roughness Ra ≤0.8μm (premium build quality).
Ultra-low Scrap Rate
Optimized pressure control reduces workpiece deformation/thread slipping; overall scrap rate controlled below 0.2% (cuts raw material waste).

Model Max.Thread Diameter(mm) Max.Length(mm) Motor(kw) Capacity (PCS/mm) Volume(L*W*H)(m) Weight(kg)
M5-65Z 5 65 3 120-140 1.50*1.30*1.10 975
M6-70Z 6 70 4 80-100 1.60*1.60*1.35 1040
M6-120Z 6 120 4 80-100 1.60*1.60*1.35 1300
M8-80Z 8 80 4 80-100 1.74*1.36*1.20 1400
M10-130Z 10 130 11 70-90 2.00*1.48*1.30 2000
M12-200Z 12 200 18.5 40-50 2.45*1.60*1.45 3100
M14-200Z 14 200 22 30-40 2.50*1.65*1.50 4800
M16-150Z 16 150 30 30-40 2.80*2.10*1.70 5500
M16-300Z 16 300 30 30-40 2.80*2.10*1.75 6000
Product Overview

Low Noise Thread Roll Machine 380V 50HZ For Electronics Industries

Low Noise Thread Roll Machine 380V 50HZ For Electronics Industries

Low Noise Thread Roll Machine 380V 50HZ For Electronics Industries

Low Noise Thread Roll Machine 380V 50HZ For Electronics Industries
Competitive Advantages

Wide Application Scope
Process most fastener materials, expanding usage scenarios in automotive, hardware, and electronics industries.

Manufacturing Excellence
Low Noise Thread Roll Machine 380V 50HZ For Electronics Industries
Low Noise Thread Roll Machine 380V 50HZ For Electronics Industries
