Specifications
Brand Name :
Heling Machine
Model Number :
M16-300Z
Place of Origin :
CHINA
MOQ :
1pcs
Price :
Welcome to Inquire
Payment Terms :
T/T
Supply Ability :
80+SET+PER month
Delivery Time :
30-40 Work days
Packaging Details :
wooden box
Name :
Thread Roll Machine
Voltage :
380V/440V/415V,50HZ/60HZ
Usage :
Efficient Automation Fully automatic continuous operation, integrating multiple processes such as straightening, cutting, forming, and thread rolling, significantly improving production efficiency and reducing labor costs. Precision and Reliability Adoptin
After-sales service provided :
Online support,Video technical support
Core components :
Bearing, motor, pump
Warranty :
1 Year
Core selling points :
Easy to operate, long service life, high productivity, patented product, automatic, multi-functional, high precision
Package :
wooden case
Color :
Customizable
Description
Cost-effective Thread Roller – Factory Supply & Premium Workmanship


Key Features

Multi-material Compatibility
Processes carbon steel, stainless steel, copper, aluminum & alloy wire (covers mainstream fastener materials).
Low Noise & Vibration
Shock-absorption base + precision gear transmission; operating noise ≤72dB (meets workshop environmental standards).
One-key Parameter Recall
Saves 15 groups of process parameters; shortens startup preparation time to 5 minutes.
Dust-proof & Moisture-proof Protection
Sealed electrical components adapt to dusty/humid workshops, reducing failure rate by 40%.

Technical Specifications
Model Max.Thread Diameter(mm) Max.Length(mm) Motor(kw) Capacity (PCS/mm) Volume(L*W*H)(m) Weight(kg)
M5-65Z 5 65 3 120-140 1.50*1.30*1.10 975
M6-70Z 6 70 4 80-100 1.60*1.60*1.35 1040
M6-120Z 6 120 4 80-100 1.60*1.60*1.35 1300
M8-80Z 8 80 4 80-100 1.74*1.36*1.20 1400
M10-130Z 10 130 11 70-90 2.00*1.48*1.30 2000
M12-200Z 12 200 18.5 40-50 2.45*1.60*1.45 3100
M14-200Z 14 200 22 30-40 2.50*1.65*1.50 4800
M16-150Z 16 150 30 30-40 2.80*2.10*1.70 5500
M16-300Z 16 300 30 30-40 2.80*2.10*1.75 6000
Product Overview

Easy Operate Thread Roll Machine High Precision Auto Feeding

Easy Operate Thread Roll Machine High Precision Auto Feeding

Easy Operate Thread Roll Machine High Precision Auto Feeding

Easy Operate Thread Roll Machine High Precision Auto Feeding








Competitive Advantages

Strong Production Adaptability
Cover Φ3–Φ16mm wire specs + multi-thread types; 10-minute mold change adapts to mass/small-batch orders.

Manufacturing Excellence
Easy Operate Thread Roll Machine High Precision Auto Feeding
Easy Operate Thread Roll Machine High Precision Auto Feeding
