380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
YJ
Model Number :
YJ series
Certification :
ISO9001 CE
Packaging Details :
Seaworthy packing
Supply Ability :
55 Sets per Year
Price :
$10,800.00 - $250,000.00/set
MOQ :
1 set
Payment Terms :
T/T, Western Union
Delivery Time :
120 days
Condition :
New
Type :
Pipe Welding Machine
Pipe Material :
Carbon steel
Application :
Drain Pipe
Production Capacity :
60-70m/min
Voltage :
380V/440V 50HZ
Power :
About 500KW for all line
Dimension(L*W*H) :
Customized
Weight :
about 40T
Warranty :
1 Year
After-sales Service Provided :
Engineers available to service machinery overseas
Factory history :
19 Years
Color :
Blue
Speed :
60-70m/min according to size and wall thickness
Raw material :
Low-carbon steel
Diameter :
60-70mm
Thickness of steel strip :
1.0-3.5mm
The width of steel strip :
60-240mm
Maximum weight coil :
2500kgs
Port :
SHANGHAI
Description

Hot Sale Tube Milling Machine Price,Steel Pipe Making Machine,Pipe Production Line

Product Description

Straight Seam High Frequency Welded Pipe Making Machine

Material: Hot/cold roll steel, galvanized steel, carbon steel

Tube Shape:Round tube, square tube, rectangular tube, special tube

Thickness: 0.4-12mm

Pipe size: round tube Φ8-Φ273mm

Working flow: hanging material→feeding→un-coiler→shear and butt welder→horizontal spiral accumulator→forming→high frequency welding→scraper→cooling →sizing→straightener→computer control flying saw→lay out table


380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line

Item Model YJ-16 YJ-20 YJ-32 YJ-50 YJ-60 YJ-76 YJ-89 YJ-114 YJ-125 YJ-165
Diameter(mm) 8-16 10-26 14-38 20-63.5 32-70 40-80 50-90 60-120 60-130 80-165
Thickness(mm) 0.3-1.0 0.5-1.5 0.6-1.8 0.8-3.0 1.0-3.0 1.0-3.5 1.5-4.0 2.0-5.0 1.5-5.5 2.0-6.0
Speed(m/min) 80-100 80-100 80-100 70-80 70-80 60-70 50-60 40-60 20-60 20-50
Host motor power(Kw) 22 37 75 132 55*2 132*2 90*2 110*2 220*2 220*2
High-frequency equipment(Kw) 60 60 100 200 250 250 250 300 300 400
Equipment composition Uncoiler, flattener, shearer welder, storing device, forming sizing unit, flying saw,
discharging table,packer, high-frequency device
Remark If you have any question, please contact us freely!

Packaging & Shipping

380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line

Our Services
  • Engineer oversea service, Guide equipment installation, commissioning, training operators.(The fee for engineer charge by buyer)
  • Seller can send engineers to guide installation and commissioning for buyer. The buyer should take up all necessary expenses for installation and engineers’ wages which include two-way air tickets, local transportation, board and lodge (average hotel), insurance, plus installation labor charge USD 80.00 per day. The buyer also needs to provide all necessary assistance such as workers and crane equipment.
  • Warranty period of one year, Warranty period provided free of charge due to quality problems of damaged parts.
  • Long-term to provide accessories, technology.
Company Information

380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line

FAQ

380v 440v Automatic Tube Making Machine 50hz Erw Pipe Production Line
