Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Steel Pipe Making Machine Pipe Production Line Tube Mill Line
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
YJ
Certification :
ISO9001 CE
Packaging Details :
Seaworthy packing
Supply Ability :
50 Sets per Year
Price :
USD15000-50000/set
Model Number :
YJ series
MOQ :
1 set
Payment Terms :
T/T, Western Union
Delivery Time :
60 days
Applicable Industries :
Building Material Shops, Manufacturing Plant
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Gearbox, Motor
Condition :
New
Type :
Pipe Mill
Pipe Material :
Carbon steel
Production Capacity :
60-70m/min
Voltage :
380V/440V 50HZ
Power :
About 500KW for all line
Dimension(L*W*H) :
Customized
Weight :
5500 kg
Warranty :
1 Year
Key Selling Points :
High-accuracy
Factory history :
19 Years
Color :
Blue
Diameter :
60-70mm
Thickness of steel strip :
1.0-3.5mm
The width of steel strip :
60-240mm
Maximum weight coil :
2500kgs
After sales Service Provided :
Field installation, commissioning and training
Port :
SHANGHAI
Description

Steel Pipe Making Machine Pipe Production Line Tube Mill Line

Product Description

Straight Seam High Frequency Welded Pipe Making Machine

Material: Hot/cold roll steel, galvanized steel, carbon steel

Tube Shape:Round tube, square tube, rectangular tube, special tube

Thickness: 0.4-12mm

Pipe size: round tube Φ8-Φ273mm

Working flow: hanging material→feeding→uncoiler→shear and butt welder→horizontal spiral accumulator→forming→high frequency welding→scraper→cooling →sizing→straightener→computer control flying saw→lay out table

Steel Pipe Making Machine Pipe Production Line Tube Mill LineSteel Pipe Making Machine Pipe Production Line Tube Mill LineSteel Pipe Making Machine Pipe Production Line Tube Mill LineSteel Pipe Making Machine Pipe Production Line Tube Mill LineSteel Pipe Making Machine Pipe Production Line Tube Mill LineSteel Pipe Making Machine Pipe Production Line Tube Mill Line

The model and basic parameters

Item Model YJ-16 YJ-20 YJ-32 YJ-50 YJ-60 YJ-76 YJ-89 YJ-114 YJ-125 YJ-165
Diameter(mm) 8-16 10-26 14-38 20-63.5 32-70 40-80 50-90 60-120 60-130 80-165
Thickness(mm) 0.3-1.0 0.5-1.5 0.6-1.8 0.8-3.0 1.0-3.0 1.0-3.5 1.5-4.0 2.0-5.0 1.5-5.5 2.0-6.0
Speed(m/min) 80-100 80-100 80-100 70-80 70-80 60-70 50-60 40-60 20-60 20-50
Host motor power(Kw) 22 37 75 132 55*2 132*2 90*2 110*2 220*2 220*2
High-frequency equipment(Kw) 60 60 100 200 250 250 250 300 300 400
Equipment composition Uncoiler, flattener, shearer welder, storing device, forming sizing unit, flying saw,
discharging table,packer, high-frequency device
Remark If you have any question, please contact us freely!

Summary
This equipment is specially used for producingΦ20-Φ80mm, δ1-4.0mm high-frequency straight seam welded pipe and corresponding square pipe (17*17-62*62mm,1.2-3.0mm). The composition of equipment is from uncoiler to fixed length cutting saw. Rolling speed can be according to suitable range of pipe diameter and wall thickness.
A. Applicable material
1 Raw material: Low-carbon steel,

2 Thickness of steel strip: 1.0-3.5mm
3 The width of steel strip: 60-240mm
4 I.D. of steel coil: Φ450-Φ550mm
5 O.D. of steel coil: Φ800-Φ1200mm
6 Maximum weight coil: 2500kgs
B .Dimension range of processing steel pipe
1 O.D of pipe: Φ20-Φ80mm
2 Wall thickness: 1.0-3.5mm (square pipe :1.2-3.0mm)
3 Length: 4-8m
4 Milling speed: 60-70m/min
5 High-frequency equipment power: 250 KW (Solid state)
6 Voltage:380V/440V,50HZ
C.Main components
1 Uncoiler: 1 set
2 Shearing and butt-welder: 1 set
3 Accumulator: 1 set
4 Forming. Welding &sizing unit: 1 set
5 Computer-controlled tracking cutting saw: 1 set
6 Run-out table: 1 set
7 Solid-state high-frequency welder: 1 set
Detailed Images

Steel Pipe Making Machine Pipe Production Line Tube Mill Line


Steel Pipe Making Machine Pipe Production Line Tube Mill Line

Hot Products

Steel Pipe Making Machine Pipe Production Line Tube Mill Line

Company Information

Steel Pipe Making Machine Pipe Production Line Tube Mill Line

Packaging & Shipping

Steel Pipe Making Machine Pipe Production Line Tube Mill Line

FAQ

Q:Are you manufacturer?
A:Yes,we are manufacturer.We have our own technical team.Welcome to visit us.

Q:What kind o f payment term you can do?
A:We are flexible about payment terms,we can also help you on financing,please contact us for details.

Q:What info you need before you make the proposal?
A:The pipe diameter and thickness range which you need or the profile drawings,material information,your special requirements.

Q: What should I do if I just start a new business?
A:Contact us immediately ,we provide free consultant pre-sales service.Also we can help you to solve the material(steel coil)purchase,worker train,international market price.

Q:How do you do QA?
A:We have special team do strict QA,this is our strengths:
(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.
(2)Every shaft will be inspected for the centering jumpiness.
(3)Every roller will be checked to make sure its in the range of tolerance critical parts will be inspected for all dimensions.

Q:Why I should choose you,what are the differences between you and other Chinese suppliers?
A:We are concentrate on this area for more than ten years,and especially our company’s YJ series spiral accumulator won a utility model patent certificate issued by intellectual property office (patent no:ZL200820132936.X).Our pipe making machine line directly export to Russia,Vietnam,India,Indonesia,and many countries in Asia.
