0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
YJ
Packaging Details :
Seaworthy packing for High quality filter bag tube steel production line sewing machine
Price :
$6500-$100,000.00/set
MOQ :
1 set
Model Number :
YJ series
Certification :
ISO9001 CE
Supply Ability :
50 Sets per Year
Delivery Time :
60 days
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Gearbox, Motor
Condition :
New
Type :
Pipe Mill
Pipe Material :
Carbon steel
Application :
Energy Supply Pipe
Production Capacity :
0-120m/min
Voltage :
220/380V
Power :
0-120m/min
Weight :
5000 kg
Warranty :
1 Year
Key Selling Points :
Automatic
Pipe material :
carbon steel,hot or cold steel,galvanized steel
Pipe diameter :
8-320mm
Pipe thickness :
0.4-12mm
After sales Service Provided :
field installation, commissioning, training
Pipe shape :
round/square/rectangle
Color :
Customer's Requirement
Description

High efficiency Round / Square pipe making machine steel tube mill line

Product Description

Straight Seam High Frequency Welded Pipe Making Machine

Material: Hot/cold roll steel, galvanized steel, carbon steel

Tube Shape:Round tube, square tube, rectangular tube, special tube

Thickness: 0.4-12mm

Pipe size: round tube Φ8-Φ273mm

Working flow: hanging material→feeding→uncoiler→shear and butt welder→horizontal spiral accumulator→forming→high frequency welding→scraper→cooling →sizing→straightener→computer control flying saw→lay out table

0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill 0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill

Specifications

0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill

Item Model YJ-16 YJ-20 YJ-32 YJ-50 YJ-60 YJ-76 YJ-89 YJ-114 YJ-125 YJ-165
Diameter(mm) 8-16 10-26 14-38 20-63.5 32-70 40-80 50-90 60-120 60-130 80-165
Thickness(mm) 0.3-1.0 0.5-1.5 0.6-1.8 0.8-3.0 1.0-3.0 1.0-3.5 1.5-4.0 2.0-5.0 1.5-5.5 2.0-6.0
Speed(m/min) 80-100 80-100 80-100 70-80 70-80 60-70 50-60 40-60 20-60 20-50
Host motor power(Kw) 22 37 75 132 55*2 132*2 90*2 110*2 220*2 220*2
High-frequency equipment(Kw) 60 60 100 200 250 250 250 300 300 400
Equipment composition Uncoiler, flattener, shearer welder, storing device, forming sizing unit, flying saw,
discharging table,packer, high-frequency device
Remark If you have any question, please contact us freely!
Packaging & Shipping

0.4-12mm Square Tube Manufacturing Machine Round Carbon Steel Pipe Mill

Our Services
  • Engineer oversea service, Guide equipment installation, commissioning, training operators.(The fee for engineer charge by buyer)
  • Seller can send engineers to guide installation and commissioning for buyer. The buyer should take up all necessary expenses for installation and engineers’ wages which include two-way air tickets, local transportation, board and lodge (average hotel), insurance, plus installation labor charge USD 80.00 per day. The buyer also needs to provide all necessary assistance such as workers and crane equipment.
  • Warranty period of one year, Warranty period provided free of charge due to quality problems of damaged parts.
  • Long-term to provide accessories, technology.
