YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine
Specifications
Brand Name :
YJ
Model Number :
YJ series
Certification :
ISO9001 CE
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
$112,800.00 - $250,000.00/sets
Supply Ability :
50 Sets per Year
Delivery Time :
120 days
Packaging Details :
Seaworthy packing
Condition :
New
Type :
Pipe Welding Machine
Pipe Material :
Carbon steel
Application :
Drain Pipe
Production Capacity :
20-60m/min
Voltage :
380V/440V 50HZ
Power :
220*2kw
Dimension(L*W*H) :
Customized
Weight :
Customized
Warranty :
1 Year
After-sales Service Provided :
Engineers available to service machinery overseas
Factory history :
19 Years
Color :
Blue
Speed :
20-60m/min according to size and wall thickness
Raw material :
Low-carbon steel
Diameter :
12.7-38.1mm
Thickness of steel strip :
0.4-2.0mm
Host motor power :
220*2kw
High-frequency equipment :
300kw
Port :
SHANGHAI
Description

YJ32 Model Steel Tube Mill Line Carbon Steel Galvanized Steel Pipe Making Machine

Product Description

Straight Seam High Frequency Welded Pipe Making Machine

Material: Hot/cold roll steel, galvanized steel, carbon steel

Tube Shape:Round tube, square tube, rectangular tube, special tube

Thickness: 0.4-12mm

Pipe size: round tube Φ8-Φ273mm

Working flow: hanging material→feeding→uncoiler→shear and butt welder→horizontal spiral accumulator→forming→high frequency welding→scraper→cooling →sizing→straightener→computer control flying saw→lay out table


YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine

YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine

YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine

The model and basic parameters

regular standard model reccommended production diamter applicable thickness production speed
YJ20 Φ10-Φ25.4mm 0.4-1.5mm 0-100m/min
8x8-20x20mm 0.4-1.0mm
10x6-25x15mm 0.4-1.0mm
YJ32 Φ12.7-Φ38.1mm 0.4-2.0mm 0-120m/min
10x10-30x30mm 0.4-1.5mm
12x8-40x20mm 0.4-1.5mm
YJ50 Φ19.1-Φ63.5mm 0.6-3.0mm 0-100m/min
15x15-50x50mm 0.6-2.5mm
20x10-60x40mm 0.6-2.5mm
YJ76 Φ38.1-Φ89mm 0.8-3.5mm 0-80m/min
30x30-70x70mm 0.8-3.0mm
40x20-80x60mm 0.8-3.0mm
YJ89 Φ50-Φ102mm 1.0-4.0mm 0-70m/min
40x40-80x80mm 1.0-3.5mm
50x30-90x70mm 1.0-3.5mm
YJ102 Φ50-Φ114mm 1.2-4.5mm 0-70m/min
40x40-90x90mm 1.2-4.0mm
50x30-100x80mm 1.2-4.0mm
YJ114 Φ63.5-Φ127mm 1.5-5.0mm 0-60m/min
50x50-100x100mm 1.5-4.2mm
60x40-120x80mm 1.5-4.2mm
YJ127 Φ63.5-Φ140mm 1.5-5.0mm 0-60m/min
50x50-110x110mm 1.5-4.5mm
60x40-130x90mm 1.5-4.5mm
YJ165 Φ76-Φ165mm 1.5-6.0mm 0-50m/min
60x60-130x130mm 1.5-5.0mm
70x50-150x110mm 1.5-5.0mm
YJ219 Φ89-Φ219mm 2.0-8.0mm 0-50m/min
70x70-170x170mm 2.0-7.0mm
80x60-190x150mm 2.0-7.0mm
YJ254 Φ114-Φ254mm 3.0-9.0mm 0-40m/min
90x90-200x200mm 3.0-7.5mm
100x80-250x150mm 3.0-7.5mm
YJ273 Φ140-Φ273mm 4.0-10.0mm 0-30m/min
110x110-215x215mm 4.0-8.5mm
130x90-250x180mm

4.0-8.5mm
Detailed Images

YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine


YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine

Hot Products

YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine

Company Information

YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine

Packaging & Shipping

YJ32 Model Carbon Steel Tube Mill Line Galvanized Steel Pipe Making Machine

FAQ

Q:Are you manufacturer?
A:Yes,we are manufacturer.We have our own technical team and factory. Welcome to visit us.

Q:What kind o f payment term you can do?
A:We are flexible about payment terms,please contact us for details.

Q:What info you need before you make the proposal?
A:The pipe diameter and thickness range which you need or the profile drawings,material information,your special requirements.

Q: What should I do if I just start a new business?
A:Contact us immediately ,we provide free consultant pre-sales service.Also we can help you to solve the material(steel coil)purchase,worker train,international market price.

Q:How do you do QA?
A:We have special team do strict QA,this is our strengths:
(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.
(2)Every shaft will be inspected for the centering jumpiness.
(3)Every roller will be checked to make sure its in the range of tolerance critical parts will be inspected for all dimensions.

Q:Why I should choose you,what are the differences between you and other Chinese suppliers?
A:We are concentrate on this area for more than 20 years,and especially our company’s YJ series spiral accumulator won a utility model patent certificate issued by intellectual property office (patent no:ZL200820132936.X).Our pipe making machine line directly export to Russia,Vietnam,India,Indonesia,and many countries in Asia.
