China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
China Dongfeng Refrigerator 4ton/5ton/6ton Light Van Cargo Truck Refrigerated Truck
Specifications
Name :
Refrigerator Truck
Place of Origin :
CHINA
Brand Name :
CLW
MOQ :
1
Price :
15000-35000 per unit
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Model NO. :
CLW5045
Payload :
1-10t
Emission Standard :
Euro 5
Transmission Type :
Manual
Horsepower :
150-250hp
Fuel :
Diesel
Bearing Capacity :
Small
Car Type :
Flatbed Style
Condition :
New
Box Size :
4800*2100*2100 mm
Box Max. Loading Weight :
5tons-8tons
Rear Lifting Platform :
Hydraulic Control
Rear Lifting Platform Loading Capacity :
1500 Kg
Seats :
≤5
Chassis Brand :
Dongfeng, Foton, FAW, HOWO, etc.
Brake :
Air Brake
Transmission :
6 Forwards and 1 Reverse
Box Volume :
20m3
Box Material :
Roofing Iron
Rear Lifting Platform Size :
2100*1800mm
Delivery Time :
25 Days After Receive The Deposit
Paint :
Color and Logo According to Customer Needs
Transport Package :
Nude, Container, RO-RO, Bulk
Specification :
7010*2330*3200 mm
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909990
Production Capacity :
500 Units Per Month
Description

Dongfeng 4ton/5ton/6ton Light Van Cargo Truck Commercial with Rear Hydraulic Lifting Platform

Description:

Strong power, super load capacity. We can provide trucks with a load capacity of up to 40 tons.

  • Warranty: One year for the engine, gear box, and axles.
  • Rear Hydraulic Lifting Platform can carry 1500 kg.
  • Technical supporting and modification according to customers' requirements are available.
Condition New condition/left hand drive/4x2










Chassis

 Brand Dongfeng
Curb weight(kg) 4500 kg
Wheelbase(mm) 3800 mm
Dimensions(mm) 7010*2330*3200 mm
Front/Rear axle loading(kg) 2500/6000 kg
Front/Rear overhang(mm) 1120/2355 mm
Wheel track (front/rear) (mm) 1685/1615 mm
Approach/Departure angle(°) 22/11
Max. driving speed(km/h) 90 km/h
Clutch Reinforced diaphragm clutch
Brake Air brake
Steering Gear Power steering, hydraulic steering with power assistance
Tire Quantity 6pcs with one spare tire
Specifications 7.50R16
Transmission Manual type, 6 Forwards and 1 reverse
Cab Single row seat, It can accommodate three people, with ABS





Engine

 Model CY4SK251
Fuel type Diesel
Displacement(ml) 3856 ml
Power(kw) 115 kw
Horsepower(HP) 156 HP
Cylinder number 4
Emission standard Euro 5
Upper



Box

 Size(mm) 4800*2100*2100 mm
Volume(m3) 20.0 CBM
Max. Loading weight(tons) 5tons-8tons
Material Roofing iron



Rear hydraulic lifting system

 Control model Hydraulic control
Control panel Close to the rear door
Panel material Carbon Steel
Size(width * height) 2100*1800mm
Max. Loading capacity(kg) 1500 kg


Remarks
  • Color is optional
  • Logo design as per customer needs
