Specifications
Rear Platform :
Optional
Truck Refrigeration Unit :
Thermoking, Carrier or Chinese Alternative
Transport Package :
Nude, Container, RO-RO, Bulk
Specification :
6000*2500*3300mm
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909990
Production Capacity :
500 Units Per Month
Place of Origin :
CHINA
Brand Name :
CLW
MOQ :
1
Price :
15000-35000 per unit
Name :
Refrigerator Truck
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Material :
Fiberglass
Model NO. :
CLW5082XT
Payload :
3ton,5ton,6ton,etc.
Emission Standard :
Euro 3, Euro 4, Euro 5
Transmission Type :
Manual
Horsepower :
150-250hp
Fuel :
Diesel
Bearing Capacity :
Small
Car Type :
Van
Condition :
New
Box Size :
4100*2300*2100mm
Delivery Time :
25 Days
Insulating Layer :
8cm Polyurethane Foam
Applicable Temperature :
-18~0 Degree
Logo :
as Per Customer's Request
Gearbox :
5 Forward & 1 Reverse
Description
Dongfeng 3ton/5ton/6ton Refrigerated Truck Cargo Truck Freezer Cooling Van Description:
  • Purpose: It used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.
  • Main parts: Refrigerating unit and control system.
  • Features: International chassis brand and International refrigerating unit brand for optional.
General Technical Parameters
Overall Dimension 6000×2500×3300(mm) Gross Vehicle Weight 11495(Kg)
Curb Weight 3900(Kg) Loading Weight 6000(Kg)
Chassis Specification









Chassis parameters

 Chassis Brand Dongfeng
Cabin Single, Left Hand Driving, with A/C



Engine

 Model 4 Cylinders
Power 88KW/120HP
Emission standard EURO V
Displacement 2.999L
Fuel type Diesel
Gearbox 5 Forward & 1 Reverse Gear
Front and Rear Axle load 2.5T/4.8T
Wheel base 3800(mm)
Overhang( Front/Rear) 1130/1505(mm)
Angle(Approach/departure) 20/16(°)
Brake System Air brake
Steering Gear Power Assistant
Tire 6 Pieces with 1 Spare Tire
Maximum speed 105(km/h)
Superstructure


Van

 Box size 4100×2300×2100(mm)
Material Fiberglass
Insulating Layer 8cm Polyurethane Foam

Brand THERMOKING
Truck refrigeration unit Model KV300

Applicable temperature (ºC) -18~0


Remarks
  • Part Optional: Ventilation slot
  • Hook
  • External power supply
  • Side door
