Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Truck Type :
15 Tons Refrigerator Truck
Name :
Carrier Refrigerated Unit
Payload :
10-15ton
Horsepower :
251-350hp
Fuel :
Diesel
Condition :
New
Chassis Brand :
Dongfeng, Foton, Sinotruk HOWO, FAW, Jmc
Refrigerator Unit Brand :
Thermo King/Carrier/Dongin Thermo/Chinese Brand
HS Code :
8705909990
Van Material :
Fiberglass, Polyurethane Foam, Stainless Steel
Trademark :
CLW
Origin :
Suizhou, China
Driving Type :
4*2 Left Hand Drive
Specification :
10000x2550x3980(mm)
Engine :
Weichai Engine, Wd615.87 (290HP)
Van Box Size :
7520X2420X2500mm
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Tire Type :
12.00r20, with 1 Spare Tire
Logo or Pattern :
as Per Customer's Request
MOQ :
1
Price :
15000-35000 per unit
Transport Package :
Nude, Container, RO-RO, Bulk
Production Capacity :
500 Units Per Month
Van Thickness :
60-80mm
Emission Standard :
Euro III/IV/V/VI
Transmission Type :
Manual
Bearing Capacity :
Medium
Car Type :
Van
Description
HOWO 10ton Carrier Refrigerator Unit 12ton 15ton Thermo King Reefer Truck 15 Tons Refrigerated Freezer Cooling Van Refrigerator Truck
Product Description

1. Purpose: It used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.

2. Main parts: Refrigerating unit and control system.

3. Features: International chassis brand and International refrigerating unit brand for optional.

Product Specification
Name HOWO 4X2 Refrigerator Truck
Dimension(LxWxH) 10000x2550x3980(mm)
Total Mass 27860Kg
Rated Payload 20000Kg
Kerb Weight 7860Kg
Passenger 3
Approach/Departure Angle 16/23
The Parameters of Chassis
Manufacture/Model HOWO/ZZ1167M4611W
Driving Type 4*2 left hand drive
Wheel Base 4600 mm
Gearbox HW13710, eleven speed lever with ten speed forward and one reverse, manual
Front/Rear Track 2041/1830(mm)
Tyre 12.00R22.5
The Number of Tyre 6+1(spare tyre)
Front/Rear Suspension 1500/1890(mm)
Leaf Spring Number 10/9+6
The Paremeters of Engine
Manufacturer/Model Sinotruck/WD615.62
Rated Power 266hp/196kw
Fuel Type Diesel oil
Displacement/Capacity 9726ml
Emission Standard Euro2
Cylinder Straight/6/intercooling
Max. torque 1100N.m
Velocity 2200rpm
The Parameters of Equipment
Wagon Body Dimension 7520x2420x2500(mm)
Color of the Wagon Customizable
Function Transporting the frozen food, dairy products, vegetable, fruit and vaccine medicine etc.
Wagon Materials Stainless steel, glass fiber reinforced plastics, aluminium alloy, or color steel plate, etc. with PU etc. sandwiched.
Wagon Thickness 10-20cm
Lowest Refrigeration Temperature(ºC) -18 DEGREE
Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck Carrier Refrigerated Unit , Refrigerated Freezer Cooling Van Truck
