HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
HOWO Refrigerated Van Truck Mini Refrigerator Van
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Model NO. :
CLW5632tx
Payload :
2ton 3ton 4ton 5ton 6ton
Emission Standard :
Euro 2
Transmission Type :
Manual
Horsepower :
120HP
Fuel :
Diesel
Bearing Capacity :
Small
Car Type :
Van
Condition :
New
Chassis Brand :
Dongfeng, Foton, Sinotruk HOWO, FAW, Jmc
Wheel Base :
3308 mm
Box Material :
Fiberglass
Refrigeration Brand :
Thermoking, Carrier or Chinese Famous Brands
Logo or Pattern :
as Per Customer's Request
Insulating Layer :
8cm Polyurethane Foam
Applicable Temperature :
-18~0
Gearbox :
5 Forward & 1 Reverse
Tire :
7.00-16
Transport Package :
Nude, Container, RO-RO, Bulk
Specification :
5995x2420x3180 mm
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909990
Production Capacity :
500 Units Per Month
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Name :
Refrigerator Truck
MOQ :
1
Price :
15000-35000 per unit
Description
HOWO 2ton 3ton 4ton 5ton 6ton Refrigerated Freezer Lorry Van Truck Mini Refrigerator Van Cooling Box Truck
Product Description

1. Purpose of the truck : transport frozen fish, meat, fresh vegetables and vaccinum, etc.

2. Main parts of the truck: Refrigerating unit and control system.

3. Features of the truck: International chassis brands and refrigerating unit brands for optional.

Product Specification
General Technical Parameters
Overall Dimension 5995×2420×3180(mm) Gross Vehicle Weight 4495 (Kg)
Curb Weight 2805 (Kg) Loading Weight 1495(Kg)
Chassis Specification










Chassis parameters

 Chassis Brand HOWO
Cabin Single, Left Hand Driving, with A/C



Engine

 Model 4 Cylinders
Power 88 KW/120 HP
Emission standard EURO II
Displacement 2780 ml
Fuel type Diesel
Gearbox 5 Forward & 1 Reverse Gear
Front and Rear Axle load 2.5T/4.5T
Wheel base 3308(mm)
Brake System Oil brake
Steering Gear Power Assistant
Tire 7.00-16, 6 Pieces with 1 Spare Tire
Maximum speed 90 (km/h)
Superstructure


Van

 Box size 4150×2300×2100(mm)
Material Fiberglass
Insulating Layer 8cm Polyurethane Foam
Refrigerator Brand Carrier

Applicable temperature (ºC) -18~0


Remarks

 Part Optional: Ventilation slot
Hook
External power supply
Side door
