Specifications
Model NO. :
ZZ1257N3647N1
Transmission Type :
Manual
Emission Standard :
Euro 5
Displacement :
8
Payload :
30T
Fuel :
Diesel
Drive Mode :
6x4
Maximum Horsepower :
300-400hp
Condition :
Used
Tyre :
New
Steering System :
Hydraulic Steering with Power Assistance
Chassis Brand :
Sinotruk Chassis
Color :
White
Cab :
Air Conditioner
Cargo Box Material :
Carbon Steel
Electric System :
Battery:2X12V/165ah; Alternator:28V-1500 Kw; Sta
Transport Package :
Naked Packing
Specification :
10245x2496x3450m
Trademark :
Sinotruk
Origin :
China
HS Code :
87019090
Supply Ability :
1000pieces/Year
Package Size :
1024.00cm * 250.00cm * 345.00cm
Package Gross Weight :
12100.000kg
After-sales Service :
6 Months
Warranty :
6 Months
Certification :
SGS
Customization :
Available | Customized Request
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Delivery Time :
7-15days
Description
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering

Product Use

The mixer truck, an indispensable powerhouse in the construction industry, is meticulously engineered for the seamless transportation of concrete. Its distinct shape has garnered it affectionate nicknames like the field snail car and olive car. These formidable trucks are equipped with cylindrical mixers, guaranteeing that mixed concrete reaches construction sites both swiftly and efficiently.
To ensure the concrete remains in prime condition and to prevent any premature setting during transit, the mixing drum is kept in perpetual rotation. Upon delivery, the mixing cylinder is immediately cleansed with water to eliminate any residual concrete, thereby preventing hardening and ensuring the mixing cylinder is fully ready for the next load.
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering

Basic Information

Drive type:
6X4
Body size:
10.25×2.5×3.998m
Front overhang/rear overhang:
1.37/3.13m
Wheelbase:
4100+1350mm
Rated load:
7.605 tons
Vehicle weight:
17.2 tons
Maximum speed:
82km/h
Front track/rear track:
Front track: 2065mm; Rear track: 1860/1860mm

Engine parameters

engine model:
Hanma Power CM6D18.345 50
Fuel type:
diesel fuel
Number of cylinders:
6 cylinders
Maximum output power:
254kW
Maximum horsepower:
345 hp
Displacement:
9.84L
Emission Standards:
National Five
Rated speed:
1900RPM

Upload parameters

Vehicle announcement:
AH5253GJB1L5
Vehicle type:
Concrete mixer truck
Top brand:
Valin
Vehicle Origin:
Anhui Ma'anshan
Stirring volume:
3.48m³

Gearbox parameters

Gearbox Model:
Hanma 8SDJ1981
Number of gears:
8 gears

Chassis parameters

Chassis Brand:
Valin
Chassis Model:
HN1250HB35D1M5J
Chassis series:
Valin Heavy Truck
Speed ratio:
5.73
Number of springs:
9/12,3/4,4/4,3/12,4/12

tire

Number of tires:
10
Tire specifications:
11.00R20,12.00R20 16PR,12R22.5

We offer an extensive selection of used tipper trucks,tractor trucks, and concrete mixer trucks from 2013 onwards, all maintained in pristine condition and available at highly competitive prices!For additional photos and detailed information, please feel free to contact us.

Important Operational Guidelines

1. Conduct a thorough inspection of all mechanical components before starting. Only proceed if the system is in optimal condition.
2. Ensure the mixing lever is set to the 'neutral' position prior to starting the vehicle.
3. Once started, position the mixing lever in the 'discharge' setting and expel any water from the cylinder.
4. When loading, place the stirring operating rod in the 'loading' setting.
5. Secure the discharge groove in the 'traveling' position before transportation to prevent swaying.
6. When shifting the joystick, always pause in the 'neutral' position before moving to the next setting.
7. Maintain a tidy construction environment. Avoid disposing of excess materials indiscriminately. After unloading, thoroughly cleanse the mixing drum, tank, and rollers. When removing concrete clumps from the cylinder, ensure that the vehicle is turned off, the key is removed, and a supervisor is monitoring the process from outside the cylinder.

Our Factory
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering


Shipment

We typically ship trucks via RO-RO vessels or bulk vessels. Specialized containers can be arranged if required.
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering


Original Spare Parts
We provide genuine spare parts and boast a comprehensive after-sales service system. Our After-market Division is committed to delivering exceptional service and ensures rapid parts delivery through a streamlined supply chain.
Customized Request Sinotruk 8m3 Diesel Concrete Mixer Truck with Hydraulic Steering
