Specifications
Model NO. :
ZZ1257N3647N1
Transmission Type :
Manual
Emission Standard :
Euro 3
Displacement :
8
Payload :
30T
Fuel :
Diesel
Drive Mode :
6x4
Maximum Horsepower :
300-400hp
Condition :
Used
Tyre :
New
Steering System :
Hydraulic Steering with Power Assistance
Chassis Brand :
Sinotruk Chassis
Color :
Customized
Cab :
Air Conditioner
Cargo Box Material :
Carbon Steel
Electric System :
Battery:2X12V/165ah; Alternator:28V-1500 Kw; Sta
Transport Package :
Naked Packing
Specification :
10245x2496x3450m
Trademark :
Sinotruk
Origin :
China
HS Code :
87019090
Supply Ability :
1000pieces/Year
Package Size :
1024.00cm * 250.00cm * 345.00cm
Package Gross Weight :
12100.000kg
After-sales Service :
6 Months
Warranty :
6 Months
Certification :
SGS
Customization :
Available | Customized Request
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Delivery Time :
7-15days
Description
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance

Product Use

Our Mixer Truck is a highly specialized vehicle, expertly crafted to facilitate the transportation of concrete, indispensable for any construction project. With its unique and recognizable design, it has garnered nicknames such as 'field snail car' or 'olive car.' Equipped with state-of-the-art cylindrical mixers, these trucks play a crucial role in ensuring the safe and efficient delivery of pre-mixed concrete to your construction site.
The mixing drum continuously rotates during transit to prevent the concrete from hardening. Once delivery is complete, the drum undergoes a comprehensive water wash to remove any remaining concrete, thus maintaining its capacity for future uses.

Basic Information
Model NO ZZ1257N3647N1 Productivity 180m²/h
Feeding Height 1380mm Vibrating Amplitude 0.9mm
Certification ISO9001: 2000 Condition Used
Color White Cbm 10/12cbm
Customlize Support Customlize Water Tank 450L
Overall Dimension 9000*2550*3950 mm Transmission Hw19710, 10f & 2r with Pto
Transport Package Nude Specification 8800x2550x3800mm
Trademark HOWO Origin Shandong
Production Capacity 200/months
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance

CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and PerformanceCE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and PerformanceCE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and PerformanceCE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and PerformanceCE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance

Product Description

Discover In-Depth Images of SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck

brand
Sinotruk Howo
Cabin
Driving type 6x4, LHD
HW76 single bed
Vehicle Main Dimensions
Overall dimensions (L x W x H)mm
10245x2496x3450
Wheel base (mm)
3600+1350
Wheel track (front/rear) (mm)
2022/2022
Approach/Departure angle(°)
16/24
Max. driving speed(km/h)
90
Engine
Type
4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Model
WD615.47
Horse Power(HP)
371
Emission standard
Euro 3
Gearbox
10 forwards & 2 reverse
Steering
Left hand drive
Tire
12R22.5 tubeless tires with one spare
Mixer Drum
Mixer Capacity
16 cubic meters
Drum thickness
6mm
Blade thickness
4mm
Tanker Material:
16MnQ345 Carbon Steel
Filling Rate(%)
59
Input Speed (m3/min)
≥2.8
Output Speed (m3/min)
≥1.2
Surplus Ratio
≤0.5
Tanker Rotate Speed(rpm)
0~17
Hydraulic Pump
Italy Brand: PMP
Drum Drive System
Hydraulic Motor
Italy Brand: PMP
Speed Reducer
Germany Brand
Radiator
KAITONG
Water Tank Volume(L)
400

We provide a wide array of used tipper trucks,tractor trucks, and concrete mixer trucks from the year 2013 onwards. Each vehicle is in excellent condition and offers competitive pricing!For more photos and detailed information, please reach out to us.

Important Considerations

1. Conduct a thorough inspection of all mechanical system components before starting to ensure they are in optimal working condition.
2. Before ignition, make sure the mixing lever is set to the 'neutral' position.
3. After starting the engine, move the mixing lever to the 'discharge' position to remove any water from the cylinder.
4. During loading, shift the stirring operating rod to the 'loading' position.
5. Secure the discharge groove in the 'traveling' position before transit to prevent any unwanted movement.
6. When maneuvering the joystick, ensure it momentarily pauses in the 'neutral' position before moving to the next.
7. Maintain a clean work environment. Avoid indiscriminate disposal of materials. After discharge, thoroughly clean the mixing drum, tank, roller, and associated parts. If entering the cylinder to remove concrete lumps, ensure the vehicle is powered down, the key is removed, and supervision is present.

Our Factory
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance


Shipment Details

We typically ship our trucks using RO-RO vessels or bulk vessels. Special containers are available upon request.
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance


Genuine Spare Parts
We provide authentic spare parts. Our extensive after-sales service system guarantees unmatched support, utilizing an efficient supply chain for prompt and dependable delivery.
CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
