Worm Shaft And Worm Gear Customizable Gear Profile Manufacturing Process and Technical Specifications
Worm Shaft And Worm Gear Customizable Gear Profile Manufacturing Process and Technical Specifications
Specifications
Brand Name :
YIZGEAR
Place of Origin :
CHINA
MOQ :
500Sets
Payment Terms :
L/C, T/T
Supply Ability :
500 Sets/Month
Delivery Time :
60 Days
Packaging Details :
Plywood Crate
Shape :
Cylindrical
Precision Grade :
High Precision
Load Capacity :
Heavy Duty
Material :
Steel
Efficiency :
High Efficiency
Application :
Transmission
Description

1)Descriptions of Worm Gear Set

The worm gear set consists of a gear (helicoidal shaft) and a turbine (gearwheel) that mesh with each other. The two components are arranged at a 90° angle for cross transmission. It is suitable for transmission systems that require a large reduction ratio and high load-bearing capacity.

2)Advantages of Worm Gear Set

  • Large transmission ratio: A single-stage transmission can provide a much higher reduction ratio than that of gears, reducing the complexity of multi-stage transmissions.
  • Smooth operation: The progressive meshing of the worm gear and the turbine reduces shock and noise, and is suitable for precision transmission.
  • Self-locking capability: Under specific design conditions, the turbine cannot drive the worm gear in reverse direction, which is suitable for safety braking scenarios.

3)Applications of Worm Gear Set

  • Automation equipment: robotic arms, indexing mechanisms of CNC machine tools
  • Transportation: Steering gear for automobiles, braking system for trains
  • Construction machinery: Elevator drive, crane deceleration device

Technical Specifications
Parameter Specification
Custom Made Available
Gear Profile Type Worm Gear
Manufacturing Process Gear Milling & Gear Teeth Grinding
Teeth Grinding Included
Module (M) Custom
Number of Teeth (Z) Custom
Pressure Angle (α) Custom
Lead Angle Custom
Accuracy Grade ISO 6 Grade/ AGMA 11Grade
Heat Treatment Carburizing/Cement Quenching
Surface Hardness 58-62HRC
Steel Code Grades Comparison
CHINA/GB ISO ГΟСТ ASTM JIS DIN
45 C45E4 45 1045 S45C CK45
40Cr 41Cr4 40X 5140 SCr440 41Cr4
20CrMo 18CrMo4 20ХМ 4118 SCM22 25CrMo4
42CrMo 42CrMo4 38XM 4140 SCM440 42CrMo4
20CrMnTi 18XГT SMK22
20Cr2Ni4 20X2H4A
20CrNiMo 20CrNiMo2 20XHM 8720 SNCM220 21NiCrMo2
40CrNiMoA 40XH2MA/40XHMA 4340 SNCM439 40NiCrMo6/36NiCrMo4
20CrNi2Mo 20NiCrMo7 20XH2MA 4320 SNCM420
