OEM ODM Rotary Cylindrical Gears Type Girth Gear And Pinion For Custom Made Horizontal Mills
OEM ODM Rotary Cylindrical Gears Type Girth Gear And Pinion For Custom Made Horizontal Mills
Specifications
Brand Name :
YIZGEAR
Model Number :
GG22081001
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
$1500/ Piece
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
20 Pieces/Month
Delivery Time :
90 Days
Packaging Details :
Wooden Crate/Pallte
Material :
ZG42CrMo
Module :
22
Face Width :
300mm
Production Time :
90 Days
Outer Diameter :
5600mm
Pitch :
69.115mm
Description

22 Module Custom Made Girth Gears For Horizontal Mills

1) Description of Girth Gear

Girth gears are used in a number of the world’s critical industries, including mining, cement and minerals.

Usually fitted to the outside of horizontal mills, rotary mills and kilns, girth gears provide the system’s primary

rotational drive and as such need to be robust, efficient and built to last.

2) Applications of Girth Gear

Girth gears are used in a number of mining, cement and minerals processing applications, including copper,

gold, silver, platinum and iron ore production where operational downtime is not an option.

3) Material of Girth Gear

Castings Steel

Technical Specifications

Parameter Specification
Custom Made Available
Gear Profile Type Cylindrical Gears
Manufacturing Process Gear Milling/Gear Hobbing
Teeth Grinding Included
Module (M) 22
Number of Teeth (Z) Custom
Pressure Angle (α) Custom
Lead Angle Custom
Accuracy Grade ISO 8-9 Grade
Heat Treatment Quenching and Tempering
Surface Hardness 230-260 HB
Steel Code Grades Comparison
CHINA/GB ISO ГΟСТ ASTM JIS DIN
45 C45E4 45 1045 S45C CK45
40Cr 41Cr4 40X 5140 SCr440 41Cr4
20CrMo 18CrMo4 20ХМ 4118 SCM22 25CrMo4
42CrMo 42CrMo4 38XM 4140 SCM440 42CrMo4
20CrMnTi 18XГT SMK22
20Cr2Ni4 20X2H4A
20CrNiMo 20CrNiMo2 20XHM 8720 SNCM220 21NiCrMo2
40CrNiMoA 40XH2MA/40XHMA 4340 SNCM439 40NiCrMo6/36NiCrMo4
20CrNi2Mo 20NiCrMo7 20XH2MA 4320 SNCM420
Production Equipment

OEM ODM Rotary Cylindrical Gears Type Girth Gear And Pinion For Custom Made Horizontal Mills

Production Process

OEM ODM Rotary Cylindrical Gears Type Girth Gear And Pinion For Custom Made Horizontal Mills
