Specifications
Payment Terms :
L/C,T/T
Model :
SK35DP
Supply Ability :
500 PCS/Month
Name :
Multi-segment Type Conductor Wire Grip
Model Number :
SK35DP
MOQ :
1 PCS
Delivery Time :
3-7days
Price :
Negotiable
Rated Load :
90-150KN
Tightening Torque :
150N.m
Packaging Details :
Plywood Case
Brand Name :
Suntech
Certification :
ISO
Place of Origin :
Ningbo
Description

Heavy Duty Conductor Gripper with 150N.m Clamp Torque


Product Overview

Large cross section conductors under high tension need a clamp that spreads force across the whole circumference, not a single point. The multi segment come along wraps the conductor with 9, 11, 13 or 15 segments so the pull is distributed evenly and the wire surface stays undamaged. SK35DP2 and SK50DP2 are rated 120KN and 150KN for conductors up to Φ35mm and Φ50mm, with a 150N.m tightening torque; orderers specify the conductor diameter so the segment set fits exactly.

Technical Specifications

Item No.

Model

Rated Load (KN)

Applicable Conductor Dia. (mm)

Tightening Torque (N.m)

Weight (kg)

13230L

SK35DP2

120

Φ35 (MAX)

150

20

13231L

SK50DP2

150

Φ50 (MAX)

150

26

Applications

· Stringing large conductors at high tension

· Building long span transmission lines

· Tensioning conductors and adjusting sag

· Heavy duty overhead line stringing work

Product Advantages

· Segmented Even Grip — 9, 11, 13 or 15 segments spread clamping force evenly over 25-50mm conductors, preventing skid and surface damage.

· 120-150KN Pull Rating — SK35DP2 delivers 120KN and SK50DP2 delivers 150KN, sized for high tension and long span conditions.

· 150N.m Torque Clamping — The 150N.m tightening torque holds the conductor firmly; specifying the wire diameter at order time gives an exact segment fit.

· ISO 9001:2008 Manufacture — Produced under an ISO 9001:2008 quality system with OEM customization available for project specific requirements.
