3 Phase High Current Temperature Rise Test System for Switchgear and Busbar – Automatic Primary Current Injection and Thermal Performance Test Equipment
3 Phase High Current Temperature Rise Test System for Switchgear and Busbar – Automatic Primary Current Injection and Thermal Performance Test Equipment
3 Phase High Current Temperature Rise Test System for Switchgear and Busbar – Automatic Primary Current Injection and Thermal Performance Test Equipment
3 Phase High Current Temperature Rise Test System for Switchgear and Busbar – Automatic Primary Current Injection and Thermal Performance Test Equipment
3 Phase High Current Temperature Rise Test System for Switchgear and Busbar – Automatic Primary Current Injection and Thermal Performance Test Equipment
3 Phase High Current Temperature Rise Test System for Switchgear and Busbar – Automatic Primary Current Injection and Thermal Performance Test Equipment
Specifications
Model Number :
SXWA
Control Mode :
Digital automatic control
MOQ :
1
Waveform Distortion :
THD ≤1%
Brand Name :
Sansion Power
Current Booster Output :
0.5KA to 15KA
Delivery Time :
30 Working Days
Packaging Details :
Plywood Case
Certification :
CE/SGS/EMS/ISO 9001
Current Capacity :
6300A high current output
Payment Terms :
L/C,T/T
Output Power :
0~20kVA AC/DC
Place of Origin :
China
Maximum Output Current :
6300A
Description

The 3 Phase High Current Temperature Rise Test System is designed for three-phase thermal testing of electrical equipment.

The system provides synchronized three-phase current output and temperature acquisition for evaluating the thermal performance of three-phase switchgear, busbars and other electrical assemblies.

Main Testing Functions
  • Three-phase high-current injection
  • Three-phase temperature rise test
  • Busbar heat-run test
  • Switchgear temperature rise test
  • Circuit breaker thermal test
  • Contact temperature measurement
  • Continuous current loading
  • Thermal stability evaluation
  • Multi-point temperature acquisition
Main Features
  • Three-phase synchronized output
  • Adjustable current
  • Automatic current regulation
  • Multiple temperature channels
  • Real-time temperature curves
  • Programmable test duration
  • Automatic shutdown
  • Data recording
  • Report generation

A current industry example describes three-phase switchgear temperature-rise systems in configurations such as 3*3000A, 3*5000A and 3*6300A, with higher-current configurations also available.

FAQ

Why use three-phase temperature rise testing?

Three-phase testing can reproduce the operating conditions of three-phase electrical equipment and allow engineers to evaluate thermal behavior across phases.

Can the three phases be controlled independently?

The control architecture can be customized according to the test requirements.

Can busbar and switchgear be tested together?

Yes, if the system capacity and test configuration are suitable for the complete test object.
