Specifications
Standard Waveform :
1.2/50μs Lightning Impulse
Model Number :
SXCY
Impulse Energy :
15kJ
Brand Name :
Sansion Power
Main Functions :
Lightning impulse withstand testing, Full-wave impulse testing, Chopped-wave impulse testing, Switching impulse testing, Insulation coordination testing, Dielectric withstand evaluation, Waveform recording, Waveform comparison, Automatic parameter calculat
MOQ :
1
Delivery Time :
30 Working Days
Test Objects :
Power transformers, Voltage transformers, Current transformers, GIS, Circuit breakers, Bushings, Insulators, Cables, Surge arresters, Switchgear
Payment Terms :
L/C,T/T
Packaging Details :
Plywood Case
Rated Voltage :
200kV
Certification :
CE/SGS/EMS/ISO 9001
System Configuration :
Impulse Generator, Charging System, Wave-Shaping Network, Voltage Divider, Control and Measurement System
Place of Origin :
China
Description
Product Description

The Lightning Impulse Test Equipment is designed for manufacturers and laboratories that need to perform standardized impulse withstand tests on high-voltage electrical equipment.

The system simulates the electrical stress associated with lightning and transient overvoltage events.

Main Functions
  • Lightning impulse withstand testing
  • Full-wave impulse testing
  • Chopped-wave impulse testing
  • Switching impulse testing
  • Insulation coordination testing
  • Dielectric withstand evaluation
  • Waveform recording
  • Waveform comparison
  • Automatic parameter calculation
  • Test report generation
Main Test Objects
  • Power transformers
  • Voltage transformers
  • Current transformers
  • GIS
  • Circuit breakers
  • Bushings
  • Insulators
  • Cables
  • Surge arresters
  • Switchgear
Why Manufacturers Need It

A transformer or switchgear manufacturer needs to demonstrate that the product's insulation system can withstand specified transient overvoltage conditions.

Impulse testing therefore becomes an important part of type testing, design verification, quality control and laboratory research.

FAQ

Can it be used for factory testing?

Yes. Impulse test systems can be designed for manufacturer laboratories and factory test departments.

Can it be integrated into a complete HV laboratory?

Yes. The impulse system can be integrated with AC withstand, DC withstand, partial discharge and other high-voltage test systems.
