2025 china supply 10 Ton Heavy Duty Steel Coil Battery Powered Material Handling Rail Electric Coil Transfer Cart
Our coil transfer cart are used to transport steel coils and pipes for metal industry.
This coil transfer Cars are designed to be an extremely cost effective, safe and flexible load moving alternative.
Our coil transfer carts are specially designed for coil, pipe and other round material transportation.
There are mounted V-shape and Roller on coil transfer cart to protect the coil stable, roller distance can be adjusted as per coil diameter, V-shape supporting and roller can also be removable from the cart for other cargo transport.
The coil transfer cart was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and products through manufacturing facilities.
when the goods are loaded, we can make sure the cart moves safely and the goods are in a very safe condition.
coil transfer cart , rail transfer cart , material transfer cart , material handling rail transfer cart , battery powered transfer cart , steel coil transfer cart , heavy duty
transfer cart , 10 ton transfer cart , heavy duty rail transfer cart , coil rail transfer cart , transfer cart supplier
coil tsfer cart , rail transfer cart , material transfer cart , material handling rail transfer cart , battery powered transfer cart , steel coil transfer cart , heavy duty transfer cart , 10 ton transfer cart , heavy duty rail transfer cart , coil rail transfer cart , transfer cart supplier
coil transfer cart , rail transfer cart , material transfer cart , material handling rail transfer cart , battery powered transfer cart , steel coilransfer cart , heavy duty transfer cart , 10 ton transfer cart , heavy duty rail transfer cart , coil rail transfer cart , transfer cart supplier
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | BXC-150t | |
| Rated Load(t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table Size (mm) | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Height(H) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Diameter (mm) | 270 | 270 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed (m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Total Power(kw) | 2 | 3 | 2.2 | 2.2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | |
| Battery Capacity(Ah) | 150 | 180 | 180 | 200 | 220 | 220 | 260 | 300 | 330 | 400 | 400 | 440 | 600 | |
| Battery Voltage(V) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | |
| Running Distance for One Charge(km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 | |
| Max Wheel Load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
PS: All Product can be customized according to your needs
Our products are not only popular in mainland China, also exported to US, Russia, India, Saudi Arabia, Germany, Japan, Canada, South Africa, Malaysia, Singapore, Hong Kong, Taipei, Brazil, Thailand, Netherlands, Syria, Turkey, Nepal etc;According to the transfer cart's table size and quantity, transported to clients by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on;The delivery time is around 30 days after clients pays the down payment.
We provide professional Coil Transfer cart , Mold transfer trolley, Ladle car, Workshop Over-Street transfer vehicle, Track Turn, Track Turntable, Track Tractor, Track Inspection Vehicle, Automation, Climbing, Hydraulic Lifting, Weighing, Explosion-Proof, High Temperature, Waterproof and other solutions. Welcome to visit our factory for cooperation!
Q: What term of payment do you accept ?
A: For the first time we cooperate, we accept 50% T/T as depoist, 50% T/T before delivery. For the return customer, we could deal with 30% T/T as depoist, 70% T/T before delivery. Also, we accept L/C.
2. Q: What is you delivery time ?
A: We will delivery the carts you ordered 45 days after we accept the prepayment.
3. Q: How do product been shipped ?
A: We export the Industrial Handling Vehicle by sea or train with full container, LCL or in Bulk.
4. Q: Do you have quality assurance for Industrial Handling Vehicle ?
A: Yes, we have one year of assurance.
