300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
Specifications
Brand Name :
BETTER
Model Number :
BXC
Place of Origin :
Xinxiang
MOQ :
1 Piece
Price :
US$3000-3500
Payment Terms :
L/C,T/T
Supply Ability :
50 Sets/Month
Delivery Time :
15-30 days
Packaging Details :
Single Package: Dimensions 300×200×100 cm; Gross Weight 1000 kg; Quantity per Package 1 unit.
Model NO. :
BXC
Product Name :
Battery-Power Transfer Cart
Usage :
Heavy Duty Material Transportation
Load Capacity :
1-300ton
Special Function :
Anti-Explosion,Heat-Resistant,Lifting,Customized
Material :
Steel
Transport Package :
The Whole Cart Will Be Packed by Tarp.
Specification :
2000*2000*500
Trademark :
BETTER
Origin :
Xinxiang
HS Code :
84289090
Production Capacity :
50 Sets/Month
Table Size :
2000*2000*500
Power Output :
5-15 kW
Battery Voltage :
48-72V
Running Speed :
0-25 m/min
Wheel Diameter :
270-600mm
Description
Electric Coil Transfer Cart

This battery-powered steel coil transfer vehicle is specifically designed for steel processing, storage, and metal service centers. It integrates a large-torque traction motor, high-capacity lithium battery pack, and complete vehicle control system into one unit, optimized for safely, efficiently, and non-destructively transporting heavy steel, aluminum, and copper coils.

Core Configuration
  • Load capacity: 10 tons, 20 tons, 30 tons, 50 tons, 80 tons (customizable up to 150 tons)
  • Power integration: Integrated battery-driven traction motor (DC/AC), 5-15 kW power output
  • Power supply: Large-capacity lithium iron phosphate/traction battery, 6-10 hour range with fast charging
  • Control system: Integrated intelligent electronic control system
  • Walking mode: Non-rail type (polyurethane wheels) / Rail type (cast steel wheels)
  • Control method: Industrial wireless remote control + Vehicle-mounted line control
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
Safety & Customization Features
Safety Configuration
  • Emergency stop button (vehicle body and remote control)
  • Anti-rolling mechanical locking + Overload protection + Center of gravity offset monitoring
  • Sound and light alarm (operation/reverse/fault) + Anti-collision buffer strip
  • Optional laser obstacle avoidance radar
Customization Functions
  • Saddle seat types: V-shaped (steel coils), curved (aluminum/copper coils), adjustable width
  • Function expansion: Hydraulic lifting, platform rotation
  • Walking mode: Omnidirectional wheels for lateral movement and in-place rotation
  • Environmental adaptation: Explosion-proof, high-temperature resistant, cleanroom types
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
Product Parameters
Model BXC-2t BXC-5t BXC-10t BXC-16t BXC-20t BXC-25t BXC-30t BXC-40t BXC-50t BXC-63t BXC-80t BXC-100t BXC-150t
Rated Load (t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size L (mm) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Table Size W (mm) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Table Size H (mm) 450 500 500 550 550 600 600 650 650 700 800 900 1200
Wheel Base (mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Diameter (mm) 270 270 300 350 350 400 400 500 500 600 600 600 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Total Power (kw) 2 3 2.2 2.2 2.2 3 3.5 4 5 6.3 8 10 15
Battery Capacity (Ah) 150 180 180 200 220 220 260 300 330 400 400 440 600
Battery Voltage (V) 48 48 48 48 48 48 48 48 48 48 72 72 72
Running Time Full Load 4.32 5.4 4.8 4.3 4 4 3.5 3.6 3.3 3 3.6 3.2 2.9
Running Distance (km) 6.5 8.1 7.2 5.1 4.8 4.8 4.2 4.3 4 3.6 4.3 3.8 3.2
Max Wheel Load (KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Recommended Rail P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100 QU100
Applications
  • Hot/Cold Rolling Plant: Transporting steel coils from coiler to cooling zone, finishing line, and storage
  • Metal processing center: Steel coil distribution among unwinding, shearing, and packaging lines
  • Steel warehouse/logistics park: Inbound, stacking, and outbound transportation of steel coils
  • Automobile/industrial equipment stamping: Supply of raw steel coils to uncoiling and blanking lines
  • Non-ferrous metal processing: Internal circulation of aluminum and copper coils within factories
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling 300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
Customization Inquiry

How can Transfer Carts be customized?

Please provide the following information:

  • What load or product will be transferred onto the cart?
  • What is the weight of the heaviest lift or load?
  • What are the dimensions? (Length; Width; Height)
  • What is the trip time and frequency? (# of Trips per, Shifts per day)
  • What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc)
  • What is the distance to travel?
  • Other relevant information or using conditions
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
Our Advantages
  • Low noise: Operates with minimal noise levels
  • Maximum safety: Comprehensive safety features for operators and materials
  • Easy operation: User-friendly design with immediate operational capability
  • Easy implementation: Operates on standard floors without complex installation
  • Suitable for all weights: Modular fabrication handles small to extremely large loads (up to 300 tons)
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
Packaging & Shipping
  • Length < 6m, width < 2.2m: Transported by 20ft container
  • Length 5.9m-12m: Transported by 40ft container
  • 2-3 sets: Full container transport
  • 1 set: LCL Container transport
  • Width beyond 2.2m: Flat rack transport (20 or 40 ft)
  • Oversized equipment: Bulk cargo transport
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling 300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling 300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
Certifications
300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling 300-ton Load Capacity Electric Coil Transfer Cart with Anti-Explosion and Heat-Resistant Features for Heavy Material Handling
