Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost
Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost
Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost
Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost
Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost
Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost
Specifications
Brand Name :
HAOBANG
Model Number :
1.5mm TPO waterproof membrane
Certification :
ISO
Place of Origin :
Shandong,China
MOQ :
1,000 square meters
Price :
Price negotiable
Payment Terms :
L/C,T/T
Supply Ability :
680000 square meters per year
Delivery Time :
6-7 work days
Packaging Details :
Packed in Roll and on Pallet
Thickness :
1.2mm/1.5mm/2.0mm
Heat Resistance :
≥90℃
Features :
Chemical Resistance / Weldability
Root Penetration Resistance :
No penetration
Transport Packages :
Tray packaging
Feathure :
excellent tensile strength
Width :
1.2m/1.5m/2.0m
Material :
Thermoplastic Polyolefin
Description

Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost


Product Description



Product Name 1.5mm TPO Roofing Membrane (Fiber Reinforced)
Material TPO
Color White


Based on thermoplastic polyolefin (TPO) material (combining the weldability of propylene-alpha-olefin copolymer resins from advanced polymerization processes with the durability of polypropylene resins), Haobang TPO-H is a homogeneous multi-layer composite thermoplastic polyolefin polymer waterproof membrane through advanced processing technology, and is used for detailed treatment of exposed roofs.

Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep CostFiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost


Technical Data Sheet



GB27789-2011 TPO Waterproofing Membrane(Type H)
Tensile Properties

Value
Tensile strength ≥ MPa 12
Elongation at rapture
% 500
Dimensional change rate on heating
% 2
Low temperature bending
- -40℃No Cracks
Watertightness
- 0.3 MPa,2h Watertight
Impact resistance - - 0.5 kg ·m, No water leakage
Peel strength at joints
N/mm 4.0 or damaged
Right angle tear strength
N/mm 60
Water Absorption Rate(70℃168h)
% 4
Heat aging (115℃)


Time - h 672
Appearance - - No blistering,cracks,delamination,sticking or voids
Tensile strength retention ≥ % 90
Elongation retention at rapture ≥ % 90
Low temperature bendability - - -40, No Cracks
Chemical resistance


Appearance - - No blistering,cracksdelaminationsticking or voids
Tensile strength retention ≥ % 90
Elongation retention at rapture ≥ % 90
Low temperature bendability - - -40℃,No Cracks
Artificial climate accelerates aging


Time - h 2500
Appearance - - No blisteringcracks,delamination,sticking or voids
Tensile strength retention
% 90
Elongation retention at break ≥ % 90
Low temperature bendability

-40℃, No Cracks
Wind uplift resistance
4.3Kpa 90


Advantages


  • Superior hot-air fusion performance;

    Great pliability under ultra-low temperature;

    Outstanding overall dimension retention;

    Remarkable tensile stretch performance;

    Strong external impact bearing capacity;

    High solar heat reflection rate;

    Power-saving eco-grade material with recyclable feature;

    Long-lasting anti-ultraviolet aging capability.


Application


  • Traffic hub venues: airport terminals, high-speed rail stations, passenger transport terminals…

    Large public architectures: conference & exhibition complexes, exhibition galleries, sports arenas…

    Modern new infrastructure: cloud data centers, warehousing logistics parks…

    Factory workshop scenarios: auto manufacturing, electronic processing, mechanical fabrication, tobacco production plants…


Specification



Each standard roll is individually encapsulated in polyethylene film. The width is 2.0m, and the length varies according to the thickness of the membrane.
  • 0.8mm 30m(Each roll weighs about 48-50kg)
  • 1.2mm 25m(Each roll weighs about 62-64kg)
  • 1.5mm 20m(Each roll weighs about 62-64kg)
  • 1.8mm 15m(Each roll weighs about 56-58kg)
  • 2.0mm 15m(Each roll weighs about 62-64kg)

Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost


Fiber Strengthened 1.5mm White Waterproof Roof Panel Labor Saving Install Minimal Upkeep Cost


FAQ



Q: Do you offer technical installation support?

A: We supply detailed installation guidelines and online technical guidance all the time. Paid on-site technical service is also available upon your request.


Q: Which payment terms do you accept?

A: We support T/T, L/C at sight and other mainstream payment methods. A reasonable deposit is required for mass orders, with balance settled before shipment.


Q: What is your usual delivery time?

A: For standard orders, the production cycle is 10–15 working days. We can also arrange priority production if you have an urgent project schedule.
