Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
Specifications
Brand Name :
TM
Model Number :
TM58D811SXX47
Certification :
UL,Rohs,Reach,ISO9001
Place of Origin :
Guangdong of China
MOQ :
500/1000/2000 pcs
Price :
Supportive
Payment Terms :
T/T, Western Union, ,Paypal
Supply Ability :
500K/year
Delivery Time :
15 Days
Packaging Details :
250pcs/tray,5000pcs/carton
Product Type  :
RJ45 Modular Connector
Jack Type :
RJ45
Number of Positions :
8
Terminals per Port :
8
LED Option :
NO
Shielded EMI Tabs :
NO
Voltage rating :
125 V
Current rating :
1.5 A
Contact resistance :
30mΩ
Insulation resistance :
500 MΩ MIN @ 500V DC
Dielectric resistance :
1000V AC RMS 50Hz. 1MIN
Durrability :
750 CYCLES MIN
Minimal Order :
5000pcs
Package :
250pcs/tray,5000pcs/carton
Description

metal RJ45 Modular Connector without shiled and Leds TM58D811SXX47

Materials:

Housing : PBT,UL94V-0 ( RoHS )
Contact Finish: T=0.3mm GOLD PLATING FU" OVER NICKEL IN CONTACT TIN PLATING OVER NICKEL IN SOLDER AREA.( RoHS )
Shielding Shell: NO Shield
All materials mates with modulat plug conforming to FCC part 68. subpart F.


Product Structure:
RJ45 Jack
1 x 1 Port / Single Port / SMT Port
Latch Down
Connector Length: 14.25 mm
Connector Width: 13.50 mm
Connector Height: 10.9 mm
Termimal Solder Pin Length: 3.3 mm
8P8C ( 8 positions 8 contacts )
90°Orientation
Without LED, let know the connection status
Without Shield,can be customized as required
We Support Custom service as required

RJ45 Without Transformer (TM58D811SXX47) Attributes:

Model: TM58D811SXX47
Place of Origin: Guangdong of China
Certification: UL,Rohs,Reach,ISO9001
Product Type : RJ45 Modular Connector
Jack Type: RJ45
Number of Positions : 8
Terminals per Port: 8
LED Option: No
Shielded EMI Tabs: No
Voltage rating: 125 V
Current rating: 1.5 A
Contact resistance: 30mΩ
Insulation resistance: 500 MΩ MIN @ 500V DC
Dielectric resistance: 1000V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN
Minimal Order: 5000pcs
Package: 250pcs/tray,5000pcs/carton
Carton size: 34*34*27cm
Delivery Time: 20 Days
Supply Ability: 5KK/year

RJ45 Female Connector (TM58D811SXX47) Mechnical Drawing:

Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47Black Metal RJ45 Modular Connector Without Shiled And Leds TM58D811SXX47
