Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Specifications
Place of Origin :
China
Condition :
New
Machine Type :
Beading Machine, Bending machine
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
Hot Product 2019
Warranty of core components :
1 Year
Core Components :
Motor
Brand Name :
TIMEWAY
Raw Material :
PIPE
Material / Metal Processed :
Carbon steel
Power :
CNC, 0.4kw
Automation :
Automatic
Extra Services :
Machining
Year :
2023
Weight (KG) :
1000
Key Selling Points :
Automatic
Warranty :
1 Year, 1-year
Applicable Industries :
Manufacturing Plant, Other
Showroom Location :
Egypt, United Kingdom, Italy, Germany, Philippines, Brazil, Peru, Mexico, Russia, Spain, Thailand, Kenya, Chile, UAE
After-sales Service Provided :
One Year
Color :
Customer Requirements
Product name :
CNC pipe bending machine
Type :
Bending Tools
Material :
Steel Material
Power Supply :
380V 50Hz 3 Phase
Quality :
Excellent
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$16,890.00/sets 1-2 sets
MOQ :
1 set
Description
Products Description
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Specification
Unit
DW25NC
DW38NC
DW50NC
Max. bending size of carbon steel(1.5D)
mm
25.1x1.6
38.1x2
50.8x2
Max. bending length of pipe
mm
1300
2100
2400
Feeding way
-
servo motor
servo motor
servo motor
Max. bending radius
mm
175
175
250
Max. bending angle
°
185
185
185
Number of bending group
groups
200
200
200
Max. bending speed of pipe
°/s
45
45
40
Max. feed speed of pipe
mm/s
700
700
700
Feed motor power
kw
0.75
1.3
1.3
Main motor power
kw
4
4
5.5
Machine dimension(LxWxH)
mm
2500x60
x1200
3800x1000
x1300
4300x900
x1300
Machine weight
kg
1000
2100
2500
Why Choose Us
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Customizable CNC Pipe Bending Machine for Customer Requirements
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
