Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216
Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216
Specifications
Table Travel (X) (mm) :
100 mm
Table Travel (Y) (mm) :
425 mm
Table Travel (Z) (mm) :
0 mm
Number of Axes :
2
Travel (W-axis) (mm) :
0 mm
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
No. of Spindles :
Single
Range of Spindle Speed(r.p.m) :
1180 r.p.m
Spindle Motor Power(kW) :
0.75
Type :
VERTICAL
Condition :
New
CNC or Not :
Normal
Place of Origin :
Henan, China
Brand Name :
TIMAC
Voltage :
220/380V
Dimension(L*W*H) :
1700x1300x1800mm
Weight (T) :
1.3 T
Warranty :
1 Year
Key Selling Points :
Competitive Price
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Construction works , Energy & Mining
Showroom Location :
Philippines, Pakistan, India, Kenya, Algeria, Ukraine
Product name :
Con-Rod Boring and Grinding Machine
Style :
Fashion
Brand :
TIMAC
Cross adjusting stroke of fixture :
80 mm
After-sales Service Provided :
Online support, Video technical support
After Warranty Service :
Video technical support, Online support
Local Service Location :
Philippines, Pakistan, India, Japan, Malaysia, Australia, UAE
Certification :
CE
Packaging Details :
Wooden cases ( can be fumigated)
Port :
China Port
Supply Ability :
65 Set/Sets per Month
MOQ :
1 set
Price :
$6,900.00/sets 3-4 sets
Description

Con-Rod Boring and Grinding Machine TM8216

Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216

Features:

1. This machine is mainly applied to bore and grind bearing holes (including copper quill and connecting-rod tile) on connecting-rod of gasoline and diesel engine in automobile, tractor and other power sources.

2. Customer also can carry out fine boring or grinding process to connecting-rod bearing seat of deformed work-piece, after grinding combining surface, to ensure the pluralism of tow center lines.

3. Equipped with various specialized fixture, TM8216 can be used to complete fine boring and grinding process to piston pin hole, gas pump bearing hole and valve seat hole etc.

Parameter:

Model

Unit

TM8216

Diameter range of boring hole

mm

40-160

Diameter range of grinding hole

mm

50-160

Centre distance of link two holes

mm

250-650

Distance from spindle center to table

mm

270

Table longitudinal travel

mm

450

Boring head motor power

kw

0.55/0.75

Grinding head rotation/revolution motor power

kw

0.55/0.37

Hydraulic system motor motor

kw

0.55

Machine dimensions (LxWxH)

mm

1700x1300x1800

Packing dimensions (LxWxH)

mm

2250x1000x1950

N.W/G.W

kg

1300/1500

Packaging & Shipping

Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216

Company Introduction

Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216

Export Cases

Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216

Exhibitions

Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216

Customers Visited

Table Travel Z mm 0 mm Con-Rod Boring and Grinding Machine TM8216

FAQ

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: 1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
2) Irrevocable LC at sight;
3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
