Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Specifications
Type :
Horizontal
Max. Length of Workpiece (mm) :
750
Structure :
Slant Bed Lathe
Machining Capacity :
Medium Duty
Width of bed (mm) :
360 mm
Spindle Motor Power(kW) :
7.5
No. of Spindles :
Single
Number of Axes :
2
Travel (X Axis)(mm) :
220 mm
Travel (Z Axis)(mm) :
850 mm
Positioning Accuracy (mm) :
±0.002
Repeatability (X/Y/Z) (mm) :
±0.001
Place of Origin :
Henan, China
Dimension(L*W*H) :
2900x1800x1600mm
Brand Name :
TIMEWAY
Model Number :
CK-45
Tool Post Stations :
8
Weight (KG) :
3200
Warranty :
1 Year
Key Selling Points :
Competitive Price
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
CNC or Not :
CNC
Machine Type :
Slant Lathe Machine
Control system :
FANUC CNC System
Precision :
High Precision Machine
Spindle speed :
2500rpm
Max. turning diamater :
210mm
Max.swing over bed :
500mm
Max. turning length :
750mm
Main motor power :
7.5kw
Machine weight :
3200kg
Condition :
New
Spindle Bore(mm) :
66
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Food & Beverage Factory, Printing Shops, Construction works , Energy & Mining
Showroom Location :
Egypt, Canada, Turkey, United States, Italy, France, Germany, Indonesia, India, Mexico, Russia, Thailand, Argentina, South Korea, Chile, Japan, Malaysia, Australia
Core Components :
Bearing, Motor, Gear, Engine
Year :
2024
Max. Spindle Speed (r.p.m) :
2500 r.p.m
Marketing Type :
Hot Product 2024
Price :
$36,985.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Product Description
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm

STANDARD ACCESSORIES:

FANUC CNC system
8-station hydraulic tool post
Hydraulic chuck
Electronic handwheel
Lubrication system
Cooling system
Work lamp
Pilot lamp
Full protection guard
Heat exchanger
Leveling blocks & bolts
Tools & tool-box
Operation manuals

OPTIONAL ACCESSORIES:

GSK
SIEMENS CNC system
Air conditioner
Hydraulic hollow chuck
Tool setter
Bar feeder
Hydraulic tailstock
Chain type chip conveyor
Specification
SPECIFICATION
UNIT
CK-45
Max. swing over bed
mm
500
Max. swing over cross slide
mm
220
Standard turning diameter
mm
210
Max. turning diameter
mm
360
Max. turning length
mm
750
Spindle speed
rpm
2500
Spindle nose
-
A2-6
Spindle bore
mm
66
Hydraulic chuck size
mm
200
Cross travel (X)
mm
220
Longitudinal travel (Z)
mm
850
X/Z-axis rapid feed speed
m/min
20/20
Hydraulic cool post type
-
80-8T
Tool section size
mm
25x25/Φ32
Tailstock quill diameter
mm
110
Tailstock quill travel
mm
100
Tailstock quill taper
-
MT4
Bed structure
-
45° Integral bed
Guideway type
-
Linear/Sliding
Main motor power
kw
7.5
Power supply
kva
30
Machine dimensions (LxWxH)
mm
2900x1800x1600
Machine weight
kg
3200
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Factory Display：
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
Slant Bed Lathe Structure CK-45 CNC Lathe Machine For Metal Max.swing over bed 500mm
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
