600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Specifications
Type :
VERTICAL
Max. Length of Workpiece (mm) :
630
Machining Capacity :
Medium Duty
Width of bed (mm) :
600 mm
Spindle Motor Power(kW) :
2.3
No. of Spindles :
Single
Number of Axes :
2
Travel (X Axis)(mm) :
630 mm
Travel (Z Axis)(mm) :
600 mm
Place of Origin :
Henan, China
Brand Name :
timeway
Model Number :
VTC630
Voltage :
220v/380v
CNC Control System :
FANUC
Tool Post Stations :
4
Weight (KG) :
5500
Warranty :
1 Year
Key Selling Points :
Easy to Operate
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Product name :
CNC Vertical Turning Lathe
Machine Type :
Vertical Lathe
CNC or Not :
CNC Lathe Machine
Model :
VTC630
Chuck size :
12'' / 15''
Color :
Customers' Requirement
X/Z axis travel :
630/600mm
Max turning diameter :
630mm
Max.swing over bed :
700mm
main motor power :
15/18.5kw
Condition :
New
Spindle Bore(mm) :
Other
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant, Construction works
Showroom Location :
Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, R
Core Components :
Bearing, Motor, PLC, Engine
Max. Spindle Speed (r.p.m) :
1000 r.p.m
Max. Turned Length (mm) :
630
Marketing Type :
Hot Product
Price :
$45,000.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Product Overview
Vertical CNC Lathe
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Features:
-VTC series CNC vertical lathe is an automatic CNC machining machine for machining the inner and outer cylindrical surface, cone surface, end surface, groove and chamfer of the parts. The machine is especially suitable for processing of plate type workpiece like the vehicle brake hub, wheel drums, clutch platens, flywheel casings, etc.
-Single-column vertical guide rail structure, vertical column, base and sliding seat are all made of high-grade gray cast iron.
-Column and slide rail are both high-frequency quenching, and the moving surface of the guide rail is plasticized to ensure long-term use,stability and accuracy retention.
-The machine spindle adopts a large torque spindle servo motor, which is suitable for strong cutting; it is also suitable for semi-finishing and finishing of parts. The spindle adopt imported NSK bearings with high rotation precision, low heat generation and low noise.
- The X/Z axis feed is automatically fed by the servo motor. The Z-axis is nitrogen balanced, and the structure is simple and reliable, and the failure rate is low.
-The X/Z axis adopts precision ball screw and imported screw special bearings to meet the requirements of high precision and high rigidity cutting.
-The spindle bearing of the machine is lubricated by thin oil, and the guide rail is lubricated by electric lubricating oil pump.
-The machine tool post adopts the electric tool post or gang type tool plate, with high accuracy and efficiency.
- Special tooling, hydraulic chuck, cooling pump, chip conveyor and chip flushing device can be configured according to user requirements.
Specification
Specifications
Unit
VTC630
Worktable diameter
mm
630
Max. turning diameter
mm
700
Worktable speed range
rpm
10-1000
Tool-post corss travel
mm
630
Tool-post vertical travel
mm
600
Tool-post rapid feed speed
m/min
10/15
Tool-post feed speed
mm/min
0.1-1000
Tool post type
-
Gang-type/V4
Tool section size
mm
32x32
X/Z-axis positioning accuracy
mm
0.01
X/Z-axis repositioning accuracy
mm
0.008
Main motor power
kw
15/18.5
X-axis feed motor power
kw
2.3
Z-axis feed motor power
kw
2.3 (brake)
X/Z-axis feed motor torque
NM
15
Machine weight
kg
5500
Accessories

STANDARD ACCESSORIES:

FANUC CNC system
Electric tools turret
Electronic handwheel
Lubrication system
Cooling system
Work lamp
Pilot lamp
Protection guard
Heat exchanger
Leveling blocks & bolts
Tools & tool-box
Operation manuals

OPTIONAL ACCESSORIES:

SIEMENS CNC system
Air conditioner
Chain type chip conveyor
CNC system Hydraulic chuck
Nitrogen balancer
Detail Images
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Factory Display：
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
600mm Travel Z Axis VTC630 Vertical CNC Lathe Machine for User-Friendly Operation
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
